Yellow 4.5mm 12 Cores Fiber Optic Armored Singlemode OFNP Cable

Name: Yellow 4.5mm 12 Cores Fiber Optic Armored Singlemode OFNP Cable
Brand: all-electronics-online.com
SKU: 831552545
Availability: InStock
Rating: 4.4 (44 reviews)

Price:	US $ 1.2-2/Meter
Min Order:	500/Meter
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	001
Cable Diameter:	4.5mm
Fiber Type:	Singlemode
Cores Count:	12
Color:	Yellow
Outer Sheath:	OFNP
Strengh Member:	Kevlar
Application:	Medicine
Type:	Single-mode Fiber
Connection Structure:	FC-LC
Certification:	CCC

Product Description

Yellow 4.5mm 12 Cores Fiber Optic Armored Singlemode OFNP Cable

PUNO is a revolutionary designed fiber optic cable that will provide the single best solution for all your fiber optic projects and usage. Micro Armor Fiber™ can be used in any channel from Telco, CATV, WAN LAN, SAN, Broadcast, DAS, Communication, Security, Indoor, Outdoor as well as Aerial installations and regardless of environmental conditions.

Keyed Characteristics
√ Extreme crushing resistance: 10 times stronger than a standard minicore cable;
√ Good mechanical and environmental characteristics;
√ LSZH / OFNR / OFNP outer jacket;
√ Strength member in aramid yarns;
√ Available with12 or 24 SM or MM fiber optics on request;
√ Long full Steel armored protection on cable.

Application:
√ Direct interface to computers with the use of "backplane" style fiber connectors;
√ High density interconnection to wall outlets or patch panels with ribbon connector interfaces;
√ Passive Optical Networks;
√ CATV, LAN, WAN;
√ Test Instrument.

Fibre Core Classification

Fibre Size/m²	9/125
Fibre Grade	OS2
Fibre Mode	Singlemode, SMF-28e
Attenuation dB/km @1310nm	0.5
Attenuation dB/km @1550nm	0.5
Sheath	Black LSZH Rated

Mechanical Data

Fiber Count	Nominal Diameter	Weight	Tension LBS (N)		Bending Radius Inches (CM)
Fiber Count	mm	Kg/km	Installation	Long-term	Installation	Long-term
12	5.0	29	22 (100)	7 (30)	2.7 (6.9)	1.8 (4.6)

Options
√ Fiber Type: G652, G655 or G657 single-mode fiber, A1a or A1b multi -mode cable, or other types of fiber;
√ Fiber Count: The fiber count is usually 2,4,6,8or12,or other specified fiber count by clints;
√ Jacket Material: Enviromental flame retardant polyvinylchloride (PVC), enviromental low smoke zero halogen flame retardant polyolefin (LSZH), enviromental halogen flame retardant polyolefin (ZRPO), enviromental thermoplatic polyurethane (TPU), or other contracted material;
√ Jacket Color: (Including color of fiber) meets the requirements of relevant standards, or other contracted color.
√ Cable Dimension: The nominal cable dimension, or other contracted dimension;
√ Delivery Length: 1km or 2km, or other contracted length;
√ Other Requirements: Other contracted special request.

Puno Optic Technology Co., Limited. Is the Chinese manufacturing company of superior quality, specialized in assembling connectors on optical fiber cable, was created on January 1, 2005 after spending three years as an incubated division, and became the international department to offer products around the world.

Today, PUNO promotes the same original culture that has made us successful over the years. We strive to incorporate the highest level of quality in every product we produce, transaction we complete, and effort we undertake.

MISSION

We work with passion to create faster connections between people, places, ideas and values.

VISION

Representing the excellence and values of Made In China worldwide.

VALUES

Quality, Innovation, Expertise, Flexibility, Collaboration, Commitment, Honesty.

MARKET

Telecomunicazioni - Telecommunications - Data Center - Broadcasting - Military - Sensor - Transportation

EXPERTISE

More than 10 years in the fiber optics field: In 2008 we developed one of the international sales office located in HK, the powerful city in China.

PARTNERSHIP

China Mobile, China Union, China Telecom, Huawei, Foxconn.
