Name: Z-Wave Smart Home Automation System Solution Air Conditioner Infrared Transponder
Brand: all-electronics-online.com
SKU: 811511445
Availability: InStock
Rating: 4.4 (122 reviews)

Price:	US $ 88-98/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	103
Application:	Air-Conditioner
Signal Transmission:	IR Remote Control
Type:	Button
Certification:	CE
Universal:	Universal
Transmission Distance:	<50m
Material:	Plastic
Battery Type:	AAA Battery
Voltage:	DC 5V ( 4X AAA Battery Backup)

Product Description

Name of Product	AC Infrared
Type of Product	103
Working Voltage	DC 5V ( 4x AAA Battery backup)
Working Temperature	-10ºC~ +50ºC
Operating Humidity	≤ 80%
Communication Technology	Z-Wave
Communication Frequency	868.42MHz /908.42MHz / 921.42MHz
Transmission Speed	9.6/40/100 k bps
Wireless Range	20~30m
Application	Smart Home Automation

The 103 is a Z-Wave to air-conditioner (AC) IR Extender and it works with any Z-Wave compliant gateway or portable controller by translating Z-Wave's Thermostat commands to AC IR control code. User can set the IR code from the built-in code library of103 through the configuration commands, or use the learning function of GR-103 through the UI on gateway. 103 also builtin a temperature sensor that allow to report your room temperature to home gateway. It can be utilized to control or monitor your room temperature by your smart phone or PC while you are at office, home anywhere or around the world.

Built-in IR code library

The built-in IR code library enables the103 to work with any Z-Wave compliant

gateway and controller. Gateway and controller will not need to have any knowledge related to IR control code. It also eliminates the needs of complicated set up

procedures and proprietary Z-Wave commands to configure the system.The IR code

library supports various brand name air conditioners found in the today's market. User

can use his controller or gateway to send a 3 digits AC IR code number (include the

brand selection) using standard Z-Wave configuration command.
