Product Description
Product Description
VCBI series high-voltage vacuum circuit breaker is a kind of indoor high-voltage switch equipment with 50/60Hz three-phase alternating current and 24kV rated voltage, which combined the technique of the ABB Corporation in Switzerland and domestic development state and manufacturing capability.
Features and Specifications
1.Designed and developed by comprehensively adopting advanced technology of our Delixi Company.
2.Fix Horizonal type / Drawout Horizonal Type for your reference
3.high breaking capacity for Main Primary Electric System usage
4.It is applied to AC 50/60 Hz, rated voltage 400/690V, rated current 200A~6300A power distribution network for distributing power and protecting circuit and power equipment from overload, undervoltage, short circuit and grounding fault
5.Accessories: Long-distace operation, Circumscribed transformer, Lock, Connection, Cntrol module accessory.
| NO | Item | Units | parameters |
| 1 | Rated voltage | kV | 12 |
| 2 | Rated insulation level | Rated lightning Impulse voltage tolerance | kV | 75 |
| 1min frequency voltage | 42 |
| 3 | Rated short-circuit breaking current | kA | 20/25 | 31.5 | 40 |
| 4 | Rated current | A | 630
1250 | 630 | 1250 | 1250 | 1600 |
| 1600 | 2000 | 2000 | 2500 |
| 2500 | 3150 | 3150 | 4000 |
| 5 | Rated thermal stability of current (RMS) | kA | 20/25 | 31.5 | 40 |
| 6 | Dynamic Stability rated current (peak) | 63 | 80 | 100 |
| 7 | Rated short-circuit closing current (peak) | 63 | 80 | 100 |
| 8 | Rated short-circuit breaking current breaking number | times | 50 |
| 9 | Frequency tolerance of the secondary circuit voltage (1min) | V | 20,000 |
| 10 | Rated operating sequence | | 0-0.3s-CO-180s-CO |
| 0-180s-CO-180s-CO(40kA) |
| 11 | Rated thermal stabilization time | s | 4 |
| 12 | Rated a single / back-to-back electric current breaking device group | | 630/400 800/400(40KA) |
| 13 | Mechanical life | times | 20,000 |
Application
The ZN63A-12 vacuum circuit-breaker is suitable for indoors type switching system which taking the air as the insulation. In the normal working condition and in circuit breaker's technical parameter scope, the ZN63A-12 vacuum circuit breaker can meet each kind of operation at the electrical network normal or abnormal condition, including switch on and switch off and braking current. Under the situation of frequent operation or needs to open breaking the short-circuit current, it will have the extremely fine performance and satisfythe requestment of switch on or switch off automatically and has the extremely high operation reliability and the service life.
The permanent magnetic actuator produces the driving force.
The permanent magnetic actuator realizes the release.
Low quantity of components
High reliable
Few maintenances
The permanent magnetic actuator realizes the locking.
Simple structure, low noise, free of maintenance.
Simple operation process
Long service life
