Shock sensor
External Shock Sensor alarm
The unit will send only one alarm SMS "Sensor alarm+lat/long" to the authorized number in 3 minutes when the sensor is triggered in arm status. Within 3 minutes, the alarm siren sound for 5 seconds when the vibration is detected in the first time and second time. The alarm siren sound for 10 seconds when vibration again. If you disarm the tracker, the times will reset.
Disarm to stop this alarm.
alarm siren
Alarm Function ( siren beeps )
Microsd memory card
Fuel sensor
Calibration of fuel sensor
Due to the different height of fuel tank and fuel level sensor specifications, tracker need to set an appropriate zero value and full range value to detect the precise fuel percentage.
Tracker can connect to car original voltage type fuel level sensor ranging from 0-5V. You can also connect add-on voltage type fuel level sensor if you cannot use the one of the original car.
Fuel Alarm
When the fuel consumption exceeds the normal standards during driving, or oil theft/leakage when the vehicle is stopped, the tracker will send "oil: xx% + Geo-info" to the authorized number at interval of 3 minutes. The siren beeps 20S.
Cancel: Send SMS command " nooil+password" to tracker.
USB Cable
Cancel logging
the first method: use USB Cable
do not use USB (Send SMS "nosave+password", e.g. nosave123456)
Configure parameters by USB
Connect tracker to computer with the optional USB cable, open the memory of the tracker, find and open the initial configuration file with notepad, operate according the instructions.
Note: Correct password is needed every time you configure the tracker.
RFID | Camera(Option, choose one only from these 2 accessories for each tracker )
RFID module is supported. RFID data can be uploaded to service center (web platform) via GPRS, and saved and displayed on the web platform.
You must set up the APN of your local GSM network for the SIM card in tracker first before using this function, Please setup the user name and password for GPRS if there is user name and password for GPRS (APN, user name and password configurations, Please refer to the following chapters)
After APN configuration, send "photo+password" to device, it will take photos and send a SMS including http link to cell phone. Click the link to get the photo from internet.
When the tracker terminal device detects DOOR/ ACC / SOS / alarm, the tracker device will be automatically ready for photo during sending the alarm and then shoot camera to upload the photo to the monitoring platform (web server).Meanwhile, the device will send SMS including http link to all authorized cell phone numbers, photo can be also requested from web server by sending command. All photos will be automatically saved in the SD card, and viewed after copied to computers through card reader.
Speed detector IC of speed governor(LM2917 weld on PCB)
Speed calibration
Due to the different signal of speed sensor and size of tire, so calibration is needed before using this function.
Send command "setspeed+password xxx", tracker will records the speed and always calculate speed accordingly.
Speed recording
Tracker will record speed every 5 seconds;
Tracker will always record the latest 48 hours data in memory (memory card) including the speed of speed sensor and GPS.
Governor mode
Send command "governor+password" to tracker, it will reply " governor ok" and switch to governor mode.
Set governor: send command "max+password 080". E.g max123456 080, 123456 is the password, 080 is the speed.
When speed approach max speed, siren beeps 5 times to warn the driver; when speed reaches or exceed the max speed, relay will be activated to limit the speed.
Cut off the Oil and Power System function deactivated in governor mode.
Cancel: send command "nogovernor+password" to tracker, it will reply "nogovernor ok".
Temperature sensor
The available temperature range is from-050ºCto +125ºC,the number should be 3 digits and temperature unit must be in upper case in SMS command
Activate temperature Alert
Send SMS command "temperature+password+space+***C, ***C"to the tracker, it will reply "temperature ok" .When the temperature is beyond the limited range, the tracker will send SMS alarm to the authorized numbers at 3 minutes interval.
For example: Send SMS "temperature123456 -020C,060C" ,when the temperature is below -20ºC or above 60ºC,the tracker will send SMS alarm to the authorized numbers at 3 minutes interval and siren beeps 30 seconds.
Deactivate temperature alerts
Send SMS command "notemperature+password" to tracker, it will reply "notemperature OK".
Celsius and Fahrenheit Switch
Switch between Celsius and Fahrenheit .The default temperature unit is Celsius, in the sms commend C =ºC F=°F
Specifications
