33UF 400V Aluminum Electrolytic Capacitor 2000hrs
| Price: |
US $ 0.01-1/Piece |
| Trade Terms: |
FOB,EXW |
| Min Order: |
5000/Piece |
| Pay Type: |
T/T,Western Union |
Aluminum Electrolytic Capacitor 105C
Features:
1) Wide temperature range -40°C~+105°C
2) Voltage range from 6.3V - 450V
3) Stable and reliable performances
4) Suitable for use in electronic circuits for coupling, decoupling bypass and filtering
Specifications:
| Items | Characteristics |
| Rated Voltage Range | 6.3~450V.DC |
| Operating Temperature | -40ºC~+105ºC |
| Range |
| Capacitance Tolerance | ±20%(M) (25ºC,100 or 120Hz) |
| Leakage Current | I≤0.01 CV +10 (μ A ) |
| Where,I:max.leakage current(μA),C:Nominal capacitance(μ F),V:Rated voltage(V)(At 25ºC after 2 minutes) |
| Dissipation Factor | Rated voltage(VdC) | 6.3 | 10 | 16 | 25 | 35 | 50~100 | 160~450 |
| tanδ | tanδ(Max.) | 0.24 | 0.2 | 0.16 | 0.14 | 0.12 | 0.1 | 0.12 |
| | (25ºC,100 or 120Hz) |
| | When nominal capacitance exceeds 1000μF,add 0.02 to the value above for each 1000μF increase. |
| Shelf Life | After storage at 105ºC for 1000 hours, the capacitors shall meet the following requirements. |
| Capacitance Change | ≤±20% of the initial value |
| D.F.( tanδ) | ≤200% of the initial specified value |
| Leakage Current | ≤200% of the initial specified value |
| Load Life | After 2000 hours application of rated voltage with rated ripple current at +105ºC,the following limits specification shall be satisfied. |
| Capacitance Change | ≤ ±20% of the initial value |
| D.F.( tanδ) | ≤150% of the initial specified value |
| Leakage Current | ≤the initial specified value |
| Others | Meet Q/RME 08-2003, GB/T 5993-2003 |
Packing:
Bulk, ammo, tape and reel
| Prod Model: |
TMCE02 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Aluminum Electrolytic Capacitor |
| Application: |
General Purpose |
| Package Type: |
Through Hole |
| Capacitance: |
>100uf |
| Tuning: |
Electrolytic Capacitor |
