35mm2 1-in 4-out Power Distributor DIN Rail Terminal Block

35mm2 1-in 4-out Power Distributor DIN Rail Terminal Block
Price: US $ 1.59-2.3/Piece
Min Order: 1/Piece
Pay Type: T/T,Western Union,Paypal
Prod Model: JUT13-35
Type: Socket Terminals
Material: Copper
Application: Power Distirbution
Certification: Ce
Brand: Utl

Product Description


UTL- JUT13 series 1-in & 4-out Power Distributors
-
JUT13-35


Product Photos:


Parameters:
Material
HousingPA66(Nylon), UL94 V-0
CoverPC
ConductorCopper Nickel plated
BlockSteel Zinc plated
ScrewSteel Zinc plated

Electrical
Voltage ratedIEC 630V
Current ratedIEC 125A
Contact resistance20mΩ max
Insulation resistanceDC1000V, 1000MΩ Min
Withstanding VoltageAC4000V, 1 Minute

Mechanical
Connection capacity1x35mm2, 4x6mm2
Stripping length10-12mm
Tightening Torgue2.0Nm(M5) max. 2.5Nm(M6)
IP rateIP40 (indoor using only)
Operating temperature-40ºC to +105ºC
InstallationDIN rail-mounted(NS35/7.5)
Panel-mounted by screws

CertificationCE, CQC



Trading Condition:
1. Low MOQ( please inquiry for more details)
2. Quick lead time ( 3-15 working days)
3. 1 Year Warranty
4. Payment: T/T, W/U, PayPal
