6f Military Fiber Optic Cable for Field Operation II Koc
| Price: |
Negotiable/Meter |
| Min Order: |
1000/Meter |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
Singlemode-G655 |
| Jacket Color: |
Black |
| Application: |
Communication |
| Type: |
Single-mode Fiber |
| Certification: |
IEC,Tlc,Reach,SGS |
| Allowed Tensile Strength: |
600n<1500n |
| Sheath Material: |
TPU |
Product Description
FeaturesGood mechanical and environmental characteristics;Flame retardant characteristics meet the requirements of relevant standards;The mechanical characteristics of jacket meet the requirements of relevant standards;Soft, flexible, easy to lay and splice, and with big capacity data transmission; ApplicationUsed as field cable;Used in outside cabling;Used in poor condition outside cabling;Used in temporary cabling, meets the requirements of repeat cabling. Specification| Fiber Count | Cable
Dimension (mm) | Cable Weight
(kg/km) | Tensile (N) | Crush (N/100mm) | Min. Bend
Radius(mm) | Range of Temperature(ºC) |
| Long Term | Short Term | Long Term | Short Term | Dynamic | Static |
| 2 | 8.3 | 46 | 600 | 1500 | 1000 | 2000 | 20D | 10D | -20~+60 |
| 4 | 8.3 | 48 | 600 | 1500 | 1000 | 2000 |
| 6 | 9.4 | 66 | 600 | 1500 | 1000 | 2000 |
Note: 1. All the values in the table, which are for reference only, are subject to change without notice; 2. The cable dimension and weight are subject to tight buffered fiber of 0.9mm outer diameter; 3. D is outer diameter of the round cable; 4. The minimum bend radius (static) is 5D when G657 fiber is used. OptionsFiber Type: G652, G655 or G657 single-mode fiber, A1a or A1b multi -mode cable, or other types of fiber;Fiber Count: The fiber count is usually 1-6, or other contracted fiber count; Jacket Material: Environmental thermoplastic polyurethane (TPU), or other contracted material; Jacket Color: (Including color of fiber) meets the requirements of relevant standards, or other contracted color;Cable Dimension: The nominal cable dimension, or other contracted dimension;Delivery Length: 1km or 2km, or other contracted length;Other Requirements: Other contracted special request.
Shenzhen KOC Communication Co., Ltd. Is specialized in fiber optic communication product manufacture. Our products range from the basic components to end products, including passive and active categories as follows: Basic Components: Connector kits, Adapter kits, Attenuator kits.
Passive products: Connector, Adapter, Attenuator, Patch-cord, ODF and enclosure.
Active products: Media converter, Transmitting and receiving assemblies, such as laser diode assembly, PD and PIN/TIA assembly, sub-assemblies such as TOSA, ROSA, BOSA.
FTTH System: Gpon: OLT, ONU, PLC
Headquarter located in Shenzhen, China, we have branch companies, representatives and distributors in Europe, America, Middle East, South Asia. KOC products are well accepted and sold in these areas.
We provide all our products with high quality, competitive price, short delivery lead time and excellent after-sales services.
