80W Electronic LED Driver 100-240V/AC

Name: 80W Electronic LED Driver 100-240V/AC
Brand: all-electronics-online.com
SKU: 815837775
Availability: InStock
Rating: 4.9 (48 reviews)

Price:	US $ 15-17.5/Piece
Min Order:	100/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

80w electronic led driver 100-240V/AC

Technical parameters

Input voltage	100-240V/AC
Frequency	48-62Hz
Power factor	PF>0.95
Over-voltage production	110%-150%rates output voltage
Dielectric strength	IP-0/P:3750V/AC/1min
Start,rise,retention time	1500ms,80ms,20ms(230VAC full load)
Operating temperature	-25~+55ºC
Relative humidity	5~95%
Dimension	1906529(mm)

Operating characteristic:
• Compliant with SELV standards with output voltage<60DC
• Efficiency>85%
• Soft start and low ripple current output
• Fit for class I protection lighting fixture
• Have multiple protection for output exception such as open circuit,short circuit,over load etc.
• Approved by over-temperature protection certification so it can be fit for class F lighting fixture
• Compliant with international standards sush as safety,EMI,anti-interference etc.
• New power supply and appearance design,solid case protection & waterproof IP67 and extreme heat dissipation that is easy installation & design of lamps.
• Work is stable,Flicker free and long service life,5years warranty.

Model and operating parameters

Constant Current
Model	Dimming Principle	Input Voltage (V/AC)	Output Power (W)	Output Current (mA)±5%	Output Voltage (V/DC)	No Load (Vmax)	PF	Efficiency	Notes
DR-CC-60	Non dimmable	100-240	60	900	33-65	78	>0.95	80%-86%
				1200	25-50	60
				1500	19-38	46
				1800	15-30	36

Constant Voltage

DR-CV-60	Non dimmable	100-240	60	4000	12V±5%	12V±5%	>0.95	78%-86%
				2500	24V±5%	24V±5%
				1700	36V±5%	36V±5%
				1200	48V±5%	48V±5%

Conformance with regulations

• EN 55015
• EN 61000-3-2CLASSIC
• EN 61000-3-3
• EN 61000-4-2,3,4,5,6,8,11
• EN 60598

Prod Model:	DR-CC-80
Dimming Range:	5%-100%
IP Degree:	IP20
Efficiency:	85%
Dimensions:	1906529(mm)
Output Power:	80W Max
Warranty:	2years
PF:	>0.95
Frequency:	48-62Hz
Operating Temperature:	-25~+55
Relative Humidity:	5-59%
Usage:	Light
Output Type:	Single
Driving Method:	LED Regulator Voltage
Circuit Structure:	PWM Controlled
Power Supply Mode:	Customed
Power Supply Voltage:	100-240V/AC
Brand:	No Brand
