9~52 Circuits Slip Ring Gtk-Cm Series Manufacture in China

Name: 9~52 Circuits Slip Ring Gtk-Cm Series Manufacture in China
Brand: all-electronics-online.com
SKU: 837450695
Availability: InStock
Rating: 5 (55 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

	GTK-CM36	GTK-CM312	GTK-CM420	GTK-CM428	GTK-CM440	GTK-CM448
A	5.50mm	5.50mm	5.60mm	5.60mm	5.60mm	5.60mm
B	34.93mm	34.93mm	35.80mm	35.80mm	35.80mm	35.80mm
C	44.45mm	44.45mm	44.45mm	44.45mm	44.45mm	44.45mm
D	14.48mm	14.48mm	12.19mm	12.19mm	12.19mm	12.19mm
E	5.08mm	5.08mm	5.08mm	5.08mm	5.08mm	5.08mm
F	22.10mm	22.10mm	25.40mm	25.40mm	25.40mm	25.40mm
G	7.87mm	7.87mm	9.53mm	9.53mm	9.53mm	9.53mm
H	2.36mm	2.36mm	1.50mm	1.50mm	1.50mm	1.50mm
I	32.56mm	32.56mm	52.40mm	52.40mm	75.30mm	75.30mm
J	9 Circuits	15 Circuits	24 Circuits	32 Circuits	44 Circuits	52 Circuits
K	3x 10Amps 6x 2Amps	3x 5Amps 12x 2Amps	4x 10Amps 20x 2Amps	4x 5Amps 28x 2Amps	4x 10Amps 40x 2Amps	4x 5Amps 48x 2Amps

Maximum speed	250RPM
Standard Number of Circuits	9,15,24,32,44 or 52
Voltage	240VDC
Continuous Amps	2A,5A,10A
Cable Specification	2A,5A,10A AWG26/20/16 Telfon
Contacting Material	Gold-Gold
Working Environment	-40°C~+80°C

Our Products Are Widely Used in: Security, Factory Autonation, Electric Instrumentation, Medical, Aerospace, Civil and Military Fields. Such as: Crane, Giant Wheel, Cotton Picker, Medical Equipment, Strander, Webcam, Automatic Revolving Door, Amusement Equipment, Irrigation Machine.....

Prod Model:	GTK-CM Series

Suzhou L. Clarke Corporation Ltd supplies different kinds of products. High quality and reasonable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.

. We warmly and sincerely welcome customers all over the world to visit our factory and look forward to establishing long term cooperation and solid relationship to make mutual benefit.
