| Prod Model: |
ISO A7-P4-D5-Q1 |
| Item No.: |
ISO A7-P4-D5-Q1 |
| Input Current: |
0-+/-20mA |
| Output PWM: |
20kHz-50kHz |
| Auxiliary Powe: |
15VDC |
| Response Time: |
1sec |
| Warranty Time: |
2 Years |
Product Description
Analog signal to PWM signal programmable converter ISO A7-P4-D4-Q1
Features:
*4-20mA/0-10v to PWM signal differ sensitively,response quickly.
*High linearity in full range
*Auxiliary power,signal input,output 2500VAC three isolation.
*Auxiliary power:5V,12V,15V or 24V DC single power supply
*low cost ultra small ,SIP-12 comply to UL94V-0 standard retardant package.
*Strong ability against EMC and high frequency signal space inference.
*Industrial temperature range:-40-+85 degree.
Typical application:
Conversion,isolation,long transmission on analog,
PLC control on industrial field and frequency converter.
Selection control Automatically
control on motor in industrial field and control on adjusting light.
Impedance on GND interference.
Control on selecting temperature of industrial boiler automatically.
Form PWM AD converter.
| Accuracy | 0.5% |
| Auxiliary power | DC5v,12v,24V,+-5% |
| Operation temperature | -40 -+85degree |
| Operation humidity | 10-90%(No condensation) |
| storage temperature | -55-+105degree |
| storage humidity | 10-95%/ no condensation) |
| Error | less than 0.5% |
| Isolation | signal input/output /auxiliary |
| insulated resistance | more than 20Mohm |
| Withstanding voltage | signal input/output /auxiliary power |
| 2500VAC,50Hz,1minute,leakage current:1mA |
| Impact resistant voltage | 1KV,1.2/50us(p-p) |
|
|
