Az-7141 Magnetic Rotary Limit Switches Lift Limit Switch

Operation speed:0.01mm`50m/swc
Operatiom frequency:Mechanical :120 operation/min electrical:30 operation min
Insulation resistance:1000MΩ (below 500VDC) 1000MΩmin (below500VDC)
Contact resistance:25MΩ Min (inital)
Dielectric strength:1000VAC 50/60HZ for 1 minutes betweeen non-continous terminal 2000VAC 50/60HZ for
1 minute between current-carrying and nin-cureent-carrying parts and between each terminal and ground
Vibration:Mechenical durability:1.000m/s2(approx 100G's)
Mechenical durability:1.000m/s2(approx 100G's)
Mechenical durability:300m/s2(approx 30G/s)
Ambient operaing temperature:-10ºC~+70ºC
Humidity:<95%RH
Service life: Mechanically:20.000.000 operation min
Electrucally:500.000 operations min
Degree protection:IEC IP65



Company information


A.Punctual delivery time:
We carry out your order into our well-organized production schedule, ensure your punctual delivery time.
Production report before your order packed.
Shipping notice and photos sent to you as soon as your order is shipped.
B.After sales service:
We Pay high Attention To Your Feed back after receive the goods.
We Provide 12 months warranty after goods arrive.
We Promise All Parts Available in lifetime use.
We Positively Revert Your Complain Within 48hours.
C.Professional Sales:
We value every Inquiry Sent To Us, Ensure Quick Competitive Offer.
We Cooperate With Customer To Bid Tenders. Provide all Necessary Documents.
We Are A Sales Team, With AllTechnical Support From Engineer Team.

YUEQING KAMPA ELECTRIC CO.,LTD
ad#666,FeiLong Electric,LiuShi Town,YueQing City,ZheJiang,China
Tel:0086-577-62729846
Fax:0086-577-62780320
Website:www.china-kampa.com
Alibaba Home: elexpert.en.alibaba.com
