Balance Electric Scooter Li Ion Lithium Ion Battery
| Price: |
US $ 25-30/Piece |
| Min Order: |
100/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
UBP-36 |
| Cycle Life: |
800 Times |
| Charge Cut-off Voltage: |
42 |
| Discharge Cut-off Voltage: |
28 |
| Capacity: |
OEM |
| Components: |
Battery Cell + BMS |
| Lead Time: |
3-10days |
| Warranty: |
12 Months |
| Quality: |
A Grade |
| Battery Cell: |
High Power 18650 |
| Application: |
E-Bike Battery Pack, Electronic Products and etc. |
| Type: |
Lithium-Ion Battery Pack |
| Connection Mode: |
Series and Parallel |
| Usage: |
Emergency Battery |
| Electrolyte: |
Lithium |
Product Description
Balance Electric Scooter li ion Lithium Ion Battery Specific Details
NO | Item | General Parameter | Remark |
| 1 | Model | UBP36-001 | |
| 2 | Standard capacity(0.2C) | 4.4Ah | |
| 3 | Rated voltage | 36V | |
| 4 | Max. charge voltage | 42V | Single Ave. charge Voltage: 4.2V |
| 5 |
Over charge protection
| Over charge detection voltage | 4.40±0.025V | |
| Over charge release voltage | 4.3±0.025V | |
| 6 | Standard charge current | 2A | 0.2C |
| 7 | Charging time | About 300 minutes | 0.2C |
| 8 | Discharge cut-off voltage | 27.5V | Single Ave. Discharge Voltage: 2.75V |
| 9 |
Over discharge Protection
| Over discharge detection voltage | 2.5±0.05V | |
| Over discharge release voltage | 2.75±0.05V | |
| 10 | Max. continuous discharge current | 5A(adjustable) | |
| 11 | Peak discharge current | 15A(adjustable) | |
| 12 | Short circuit protection | Detection delay time | XXμs | Release condition | Cut-off load |
| 12 | Battery dimension | 135*85*55mm | |
| 13 | Net weight(Approx.) | About 1.15kg | |
| 14 | Operation temperature | Standard | 0~45 | |
| Discharge | -20~65 | |
| Storage | -20~65 | |
Payment Terms
1.We accept bank transfer(T/T) ,western union,PayPal,Cash.
2.If you prefer other payment method,please contact us by email.
cell models:
| No. | Model. | Description | Weight(g) | discharge |
|
|
| 1 | USA K2 IFR 18650P 3.2V | 1200mAh | 45 | 30C/60C |
| 2 | IFR 18650P 3.2V | 1100mAh | 45 | 20C/30C |
| 3 | IFR 18650E 3.2V | 1500mAh | 45 | 3C/5C |
| 4 | USA K2 26650Ev 3.2V | 3200mAh | 85 | 5C/10C |
| 5 | USA K2 26650P 3.2V | 2600mAh | 85 | 30C/60C |
| 6 | IFR 18650P 3.2V | 1500mAh | 45 | 15C |
| 7 | IFR 38120S 3.2V | 10Ah | 330 | 5C/8C |
| 8 | IFR 38120P 3.2V | 10Ah | 330 | 10C/20C |
| 9 | ICR 18650E 3.7V | 2200mAh | 45 | 3C |
| 10 | ICR 26650E 3.7V | 4000mAh | 82 | 2C |
| 11 | ICR 26650E 3.7V | 4500mAh | 82 | 2C |
| 12 | ICR26700E 3.7V | 5000mAh | 85 | 2C |
| 13 | SAMSUNG INR18650-13P/13L | 1300mAh | 44.5 | 10/20C |
| 14 | SAMSUNG INR18650-15K | 1500mAh | 44.5 | 10C |
| 15 | SAMSUNG INR18650-15Q | 1500mAh | 44.5 | 12C |
| 16 | SAMSUNG INR18650-15M | 1500mAh | 44.5 | 18C |
| 17 | SAMSUNG INR18650-13Q | 1300mAh | 44.5 | 15C |
| 18 | SAMSUNG INR18650-20Q | 2000mAh | 44.5 | 8C |
| 19 | SAMSUNG INR18650-20R | 2000mAh | 44.5 | 11C |
| 20 | SAMSUNG ICR18650-22FM | 22OOmAh | 45 | 2C |
| 21 | SAMSUNG ICR18650-22P 3.7V | 2200mAh | 45 | 5C |
| 22 | SAMSUNG ICR18650-26F/26FM/26H | 2600mAh | 45 | 2C |
| 23 | SAMSUNG ICR18650-28A | 2800mAh | 45 | 2C |
| 24 | SAMSUNG ICR18650-29E | 2900mAh | 45 | 2C |
| 25 | SAMSUNG ICR18650-30A/30B | 3000mAh | 45 | 2C |
| 26 | SAMSUNG ICR18650-32A | 3200mAh | 48 | 2C |
| 27 | Panasonic NCR18650PF | 2900mAh | 45 | 2C |
| 28 | Panasonic NCR18650BD | 3200mAh | 47 | 3C |
| 29 | Panasonic NCR18650B | 34OOmAh | 45.9 | 1C |
| 30 | Panasonic NCR18650A | 3100mAh | 45 | 2C |
| 31 | LG 18650 HE2 | 2500mAh | 48 | 12.5C |
| 32 | LG 18650 D1 | 3000mAh | 48.5 | 2C |
| 33 | LG 18650 C2 | 2800mAh | 48 | 2C |
| 34 | LG 18650 B4 | 2600mAh | 48 | 2C |
| 35 | LG 18650 S3 | 2200mAh | 48 | 2C |
| 36 | LG 18650 MF1 | 22OOmAh | 48 | 5C |
Introduction
Shenzhen Ubetter Co., Ltd, founded in 2013, has become a comprehensive battery manufacturer with the combination of R&D, manufacturing, marketing and service.
Shenzhen Ubetter, The Leader of Li-ion polymer batteries manufacturer, located in Shenzhen city, is specialized in Power battery series(such as electric-bikes, electric scooter and electric cars, etc), Storage battery, High-rate discharge Lithium ion battery(10C-60C high-rate discharge series such as air modeling and power tool etc), ). High Temperature Li-ion battery(up to 85° ), Low Temperature Polymer Li-ion battery(up to -40° ), Ultra-thin battery(up to 0.43mm). Ubetter has succeeded to solve the power battery core technologies problem: High Consistency and Excellent Safety Performance. Products' performance is leading in domestics market and in path with international standards. Products are widely employed in digital products series(such as MP3, UPS, etc. ), notebook PC series, 18650 series, and sales over 100 countries worldwide.
With over 4000 square meters dust-free workshop, 200 employees, automatic production lines and modernized equipments, Ubetter is offering reliable quality, efficient delivery and competitive price, by which we have gained global reputation. We are qualified for ISO9001, UL, CE, RoHS, IEC, UN38.3, MSDS, patent approves and National Hi-TECH Enterprise certification.
Our advantages
Shenzhen Ubetter Technology Co., Ltd. is a famous enterprise in the line of China's new energy business, mainly producing environmentally friendly power battery for electric vehicles, integrating the research and development, producing and selling of Lithium-ion Battery, wind and solar Energy Storage Battery as well as various kinds of batteries. Bearing with the spirit of pragmatism and innovation, we have been endeavoring to produce products with best quality for all walks of life by people-oriented management and high efficiency production line. Our R&D department has mustered skilled persons with over ten years' experience in battery research and developing, playing an leading role in the field of R&D of more and more series of batteries. Meanwhile we have cooperated with many big battery enterprises for many years and have numerous connections in this line of business. We have abundant battery resources with guaranteed quality. Shenzhen Ubetter Technology Co., Ltd. is located in the beautiful Dapeng bay with charming and beautiful scenery, excellent geographical location and convenient transportation.
