Buried Fiber Optic Cable with Stranded Loose Tube

Name: Buried Fiber Optic Cable with Stranded Loose Tube
Brand: all-electronics-online.com
SKU: 816762265
Availability: InStock
Rating: 4.6 (21 reviews)

Price:	US $ 0.1-0.9/Meter
Min Order:	10000/Meter
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

-------------------------------------------------------PRODUCT----------------------------------------------------
[General]
1. Name: Buried Fiber Optic Cable with Stranded Loose Tube
2. Item Code: GYTY53
3. Characteristics:
1) With good crush resistance and moisture-proof performance
2) Reasonable structure design and precise control for over length ensuring excellent characteristics of mechanical tensile strain and environment temperature
3) High strength loose tube material with good performance of hydrolysis resistant, special tube filling compound ensure a critical protection of fiber.
4. Picture:

[Specification]

Core Number	2-36	38-60	62-72
Diameter (mm)	12.6	13.2	13.6
Weight (Kg/km)	145	160	170
Tensile Strength Long/Short Term (N)	1000/3000	1000/3000	1000/3000
Crush Resistance Long/Short Term (N/100mm)	1000/3000	1000/3000	1000/3000
Bending Radius Static/Dynamic (mm)	10/20	10/20	10/20
Storage/operating Temperature (ºC)	-40~+70	-40~+70	-40~+70

[Packing]

-------------------------------------------------------COMPANY----------------------------------------------------
[Overview]

[Workshop]

[Storehouse]

[Trade Show]

-------------------------------------------------------CONTACT----------------------------------------------------
Shengda Cable Co Ltd
Address: No.100, Changbao West Rd, Ronggui, Shunde, Foshan, Guangdong, China
Website: www.shengda-cable.com
Contact: Derek Li
Tel: 86-757-2638-9090
Fax: 86-757-2662-5464
Cell: 86-139-2487-1973

Prod Model:	GYTY53
Application:	Communication
Type:	Single-mode Fiber
Connection Structure:	FC-FC
Certification:	ETL
Allowed Lateral Pressure:	1000/3000 (N/100mm)
Allowed Tensile Strength:	1000/3000 (N)
Brand:	Shengda
Sheath Material:	LSZH

Shengda Cable Co Ltd, formerly known as Shun Fat Electric Manufactory, is affiliated to Shun Fat Innovations Limited, a company incorporated in Hong Kong. Located in Pearl River Delta, the most dynamic region in China Mainland, Shengda enjoys the benefits of what a center of advanced manufacturing and modern service industries brings.

Established in 1985, Shengda has over 300 skilled workers and a team of marketing and engineer experts. In October 2006, Shengda moved its office and factory into Shunde High Tech. Industrial Park, the most famous high tech. Industrial center in China. Shun Fat has a factory site of over 40, 000 square meters. In its 20, 000- square- meter gardenesque workshop, there are series of integrated production appliances, among which are 4 physical foaming machines, 4 PVC Jacket extrusion machines, 2 machines for production of alarm and security cables. There are also over 400 sets of braiding machines, 100 of them are of high speeding and the remaining are of multi-function. To make sure the quality control mechanism works effectively, Shengda is equipped with various kinds of testing instrument and facilities.

Shengda manufactures wide range of products from coaxial cables to security cables with a capacity of over 250, 000 kilometers and annual turnover of nearly RMB100 million. Its products meet standard globally and have been certified or approved by ISO9001, , CCC for China, UL & ETL for US, CSA for Canada, CE & LVD for Europe.

Shengda takes pride in its human assets, its professional staff with caring minds to serve and to improve. Shengda and its working team are making continuous efforts to pursue perfectionism in providing products and service.
