Ce Approved High Efficiency IE2 Asynchronous Induction AC Motor

Name: Ce Approved High Efficiency IE2 Asynchronous Induction AC Motor
Brand: all-electronics-online.com
SKU: 809953795
Availability: InStock
Rating: 4.8 (71 reviews)

Price:	US $ 29-35/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Motor will be 100% copper wise.
Body and Housing will be cast Iron.
Bearing will be high quality
High efficiency
CR800 stator

with connection Y/Δ

Base center height: 71 ~ 355mm

Power range: 0.75 ~ 375kW

Rated voltage: 220V/380V,380/660V

Rated frequency: 50Hz (or 60Hz)

Protection: IP55 or IP54

Insulation class: F class

Cooling method:IC411

Duty: S1

Mounting and Y2 series of the same

	IE2 standard three phase induction motor
NO.	Model	Output	Speed	Voltage	stator	frequency	housing	mounting	Protection	Insulation
		kW	r/min	V

1	YE2-80M1-2	0.75	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
2	YE2-80M2-2	1.1	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
3	YE2-90S-2	1.5	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
4	YE2-90L-2	2.2	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
5	YE2-100L1-2	3	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
6	YE2-112M-2	4	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
7	YE2-132S1-2	5.5	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
8	YE2-132S2-2	7.5	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
9	YE2-160M1-2	11	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
10	YE2-160M2-2	15	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
11	YE2-160L-2	18.5	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
12	YE2-180M-2	22	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
13	YE2-200L1-2	30	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
14	YE2-200L2-2	37	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
15	YE2-225M-2	45	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
16	YE2-250M-2	55	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
17	YE2-280S-2	75	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
18	YE2-280M-2	90	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
19	YE2-315S-2	110	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
20	YE2-315M-2	132	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
21	YE2-315L1-2	160	2860	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
22	YE2-315L2-2	200	2860	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
	YE2-80M1-4	0.55	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
23	YE2-80M2-4	0.75	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
24	YE2-90S-4	1.1	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
25	YE2-90L-4	1.5	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
26	YE2-100L1-4	2.2	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
27	YE2-100L2-4	3	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
28	YE2-112M-4	4	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
29	YE2-132S-4	5.5	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
30	YE2-132M-4	7.5	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
31	YE2-160M-4	11	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
32	YE2-160L-4	15	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
33	YE2-180M-4	18.5	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
34	YE2-180L-4	22	1470	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
35	YE2-200L-4	30	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
36	YE2-225S-4	37	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
37	YE2-225M-4	45	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
38	YE2-250M-4	55	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
39	YE2-280S-4	75	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
40	YE2-280M-4	90	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
41	YE2-315S-4	110	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
42	YE2-315M-4	132	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
43	YE2-315L1-4	160	1450	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
44	YE2-315L2-4	200	1450	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
45	YE2-80M2-6	0.55	960	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
46	YE2-90S-6	0.75	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
47	YE2-90L-6	1.1	960	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
48	YE2-100L1-6	1.5	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
49	YE2-112M-6	2.2	960	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
50	YE2-132S-6	3	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
51	YE2-132M1-6	4	960	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
52	YE2-132M2-6	5.5	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
53	YE2-160M-6	7.5	960	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
54	YE2-160L-6	11	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
55	YE2-180L-6	15	960	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
56	YE2-200L1-6	18.5	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
57	YE2-200L2-6	22	960	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
58	YE2-225M-6	30	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
59	YE2-250M-6	37	960	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
60	YE2-280S-6	45	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
61	YE2-280M-6	45	960	380-415	CR800	50/60HZ	CAST Iron	B3,	IP55	F
62	YE2-315S-6	75	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
63	YE2-315M-6	90	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
64	YE2-315L1-6	110	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F
65	YE2-315L2-6	132	960	380-415	CR800	50/60HZ	CAST Iron	B3	IP55	F

FAQ:

Q: What is the payment terms?

A: 30% T/T in advance, 70% before shipment, L/C at sight, Western Union or Paypel

Q: What is your delivery time?

A: Within 25-30 days after receiving deposit.

Q: Do you offer OEM service?

A: Yes. We accept OEM service.

Q: What is your MOQ of this item ?

A: 10PCS per item.

Q: Can we type our brand on it?

A: Yes of course.

Q: Where is your loading port ?

A:Ningbo Port, zhejiang, China.

Q: What is your production capacity?

A: About 200PCS per day.

Prod Model:	YE2801-2
Stator:	Cr800
Power Range:	0.55 ~ 375kw
Rated Frequency:	50Hz or 60Hz
Protection:	IP55
Insulation:	F
Number Of Stator:	Three-Phase
Function:	Control
Certification:	Ce

Zhejiang Fanglei Machine & Electric Co., Ltd. is located in Zhejiang, East China Sea in Taizhou. Ointly established the production of small and medium-sized production base for kinds of electric motors. The company focus on R & D and production of the wider use of technology, advanced small and medium-sized electric motors for domestic and foreign markets, the main products are in line with the international IEC standard three-phase asynchronous motors Y series cast iron motor and Y2 series with cast iron and aluminum housing motor

History: 25 years experience of manufacturing stator, motor, water pumps;

Scale: Covers working area of 6, 000 square meters. Have more than 200 employees;

Technology: A group of professional technical engineers and a strong R&D team;

Management: Scientific management and strict quality control system;

Equipments: Advanced automatic production line and test equipment;

Innovation: Continuously diversify products range to satisfy customers'needs, Production capacity: 30, 000 PCS/month;

Marketing network: Europe, Asia, Africa, America, etc;

Certificate: CE, GS, RoHS, IS09001: 2008,

The company established a strong R & D team to continuously optimize the product design and manufacturing processes, improve quality control and advanced production testing equipment, with the characteristics of modern management model, the company strictly in accordance with international standards ISO9001: 2008 quality system
