China Pure Sine Wave Power Frequency 6kVA/10kVA Battery Backup Power Supply
| Price: |
US $ 3500-3900/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Paypal |
Pure Sine Wave Power Frequency 6kVA/10kVA UPS Power Supply
MZT9830L in high-power three-phase input three-phase output series UPS, stand
alone capacity from the 10 kva to the 400 kva, this series of products is the use of advanced
DSP digital technology, cooperate with high-speed 16-bit digital chip, ASIC DDC control
technology with the perfect combination of advanced high power devices IGBT and SCR,
designed the large capacity, high reliability and excellent performance of intelligent UPS.
This series of products is the most advanced internation al latest hardware and software
combination of crystallization, Can provide multiple machines running parallel operation.
This series of products are widely used in communications center, precision instruments,
CAD, CAM, hospitals, military facilities, CNC equipment, SMT equipment, IT industry,
computer and peripheral equipment, multi-line slicing machine and large motor, etc.
MZT9830L series product characteristics and application fields
By 12 SCR (silicon controlled rectifier) near the inverter side and roadside dual non
contact static switch, to ensure that the inverter power supply and the bypass uninterrupted
switch between power supply, and make sure the output voltage waveform is continuous
and smooth.Control circuit adopted a "zero" switching technology, ensures the UPS in
synchronous phase lock switch time 0 ms, out of sync with power grid, switching time is less
than 4 ms, no matter how to change, namely the gri d frequency all can ensure the UPS
output voltage, frequency stability and uninterrupted.
MZT9830L series UPS has extremely strong self-diagnosis function, the whole machine
set up 32 sensors, point to point with DSP detection and response of the ultra-high speed,
makes MZT9830L series UPS self protection function is perfect, as many as 200 of the fault
information prompt, and equipment parameters setting, real-time information data record
diagnostic function to protect the UPS into the state in time, in addition, the machine is
special equipment for emergency shutdown system is designed.
Can automatically adjust the 1 a - 50 - a large current charger, battery since the diagnosis
and maintenance system, since the choice of the battery maintenance mode, the batter y
automatic alarm system, batter y regularly circulation system, selection of no-load protection
Settings, etc.
MZT9830L panel (g) series UPS is equipped with a large screen
super bright backlit LCD touch sc reen, 320 * 240 dot matrix of the
display mode in Chinese, is completely suitable for domestic users
to use and operation.
LCD displays more than 200 information to real-time cycle
shows the utility and UPS running state.MZT9830L set series UPS
panel has many functions and parameter Settings button, fully
realized the man-machine interactive two-way dialogue, so to speak,
Dual static switch
Self diagnose and self protection
Rechargeable battery intelligent management
The man-machine dialogue with the remote monitoring and
network management
Main characteristics:
LCD panel | Model | MZT101 | MZT102 | MZT103 | MZT104 | MZT106 | MZT108 | MZT110 | MZT112 | MZT115 |
| capacity | 1KVA | 2KVA | 3KVA | 4KVA | 6KVA | 8KVA | 10KVA | 12KVA | 15KVA |
| imput | Voltage | single phase160-275VAC |
| frequency | 50(60)HZ±5% |
| current | 6A | 12A | 18A | 24A | 34A | 45A | 56A | 66A | 82A |
| output | Voltage | single 220VAC,±1% |
| frequency | 50(60)HZ |
| load power factor | 0.8lag |
| distortion factor | <3%Linear load |
| peak factor | 3:1(max) |
| battery | Voltage | 48VAD | 192VAD |
| charging time | 8-10hours |
| overall efficiency | >85% | >90% |
| communication interface | RS232 connector;RS485&DB9 |
| environment | temperature | 0-40ºC |
| altitude | <1000m |
| noise | <58dB |
| standard | output and input | termianl |
| Weight(kg) | 25 | 35 | 45 | 52 | 60 | 75 | 80 | 90 | 120 |
| Dimenson(mm) | 200*600*490 | 230*580*540 | 230*580*700 | 310*590*870 |
| | | | | | | | | | | |
| Model | MZT206 | MZT210 | MZT212 | MZT215 | MZT220 | MZT225 | MZT230 | MZT240 | |
| capacity | 6KVA | 10KVA | 12KVA | 15KVA | 20KVA | 25KVA | 30KVA | 40KVA | |
| imput | Voltage | | |
| frequency | | |
| current(Max) | 21.6A | 36.1A | 43.2A | 53.6A | 72.2A | 89.7A | 108A | 144A | |
| output | Voltage | | |
| frequency | 50(60)HZ | |
| load power factor | 0.8lag | |
| distortion factor | <3% | |
| peak factor | 31(Max) | |
| battery | 192VDC | 192VDC | |
| charging time | 8-10hours | |
| overall efficiency | >90% | |
| communication interface | RS232connector;RS485,DB9 | |
| environment | temperature | 0-40ºC | |
| altitude | <1000m | |
| noise | <58dB | |
| standard | output and input | termianl | |
| Weight(kg) | 70 | 85 | 95 | 120 | 160 | 190 | 230 | 270 | |
| Dimenson(mm) | 230*580*700 | 310*590*870 | 410*670*935 | 730*455*1180 | |
| Model | MZT2010 | MZT2015 | MZT2020 | MZT2025 | MZT2030 | MZT2040 | MZT2050 | MZT2060 | MZT2080 |
| capacity | 10KVA | 15KVA | 20KVA | 25KVA | 30KVA | 40KVA | 50KVA | 60KVA | 80KVA |
| imput | Voltage | 304-456VAC |
| frequency | 50(60)HZ±5% |
| Frequency tracking rate | 1HZ/S |
| power factor | >0.97 |
| current | 16A | 24A | 32A | 40A | 56A | 64A | 80A | 105A | 128A |
| output | Voltage | 220VAC±1%or230VAC±1% |
| frequency | 50HZ/60HZ±5% |
| frequency factor | 0.8 |
| waveform distortion | Linear load≤0%,nonlinear load |
| overload capacity | overload110-150%To bypass the power supply lasts for 5 minutes |
| peak factor | 3:1(max) |
| transfer time | Oms |
| battery | Voltage | 360V | 384V |
| charging time | 8-10hours |
| overall efficiency | >92% | 93% |
| protective function | Electronic short circuit protection;Current limiting protection for 1-3 times the rated current |
| panel | LED | Battery low boltage,inverter,bypass,abnormal condition,overload indicator |
| LCD | BIOS interface,frequency,battery voltage,load percentage,temperature in driers |
| Communication interface | RS232&SNMP |
| work environment | temperature | 0~40ºC |
| humidity | 0-95% |
| Storage temperature | 025ºC-55ºC |
| Service altitude | <1500 |
| noise | | | 55~68 |
| physical characteristics | Weight(kg) | 155 | 240 | 297 | 326 | 336 | 352 | 355 | 415 | 468 |
| Dimenson(mm) | 720*450*1130 | 855*450*1230 | 1000*660*1460 |
| executive standard | UD/T 1095-2000 |
| | | | | | | | | | | |
1. Welcome your enquiryContact me :leon liang Mob:+86 18824648626
| Prod Model: |
MZT9830L SERIES |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Works As Well As Principle: |
Uninterrupted Switch |
| Phase: |
Three Phase |
| Type: |
On-line |
| Protection: |
Overvoltage Short Circuit Overcurrent Unbalanced |
| Application: |
Fire Safety Defence Communication Spaceflight |
| Brand: |
Meze |
Meze company was founded in 1999, so far, has developed into a comprehensive power supply enterprise, products include: UPS uninterruptible power supply, microcomputer non-contact electronic AC regulated power supply, EPS emergency power supply, etc. Main range: The financial, government, research institutes, transportation, aerospace, electronics, medical, services, etc. To meet the global electronic and communication industry for power equipment is increasingly vigorous market demand, Due to the need of development, shenzhen Meze power technology Co., Ltd was established in 2008 (Specialize in UPS power frequency, regulated power supply, and transformer) In the same year registered Meze electronics Co., Ltd. (Terminal blocks, all accessories of PCB), In 2011, registered shenzhen Meze mechanical and electrical Co., Ltd. ( SMT placement machine and accessories ).
Existing number of employees: 180-180 employees, Using area: 3000 square meters, Company has the high technology and rich experience, Products from well-known international brands of Europe, is committed to providing customers with the full range of high quality high performance high stable power supply protection. Using the international advanced intelligent digital UPS power supply technology, and the most advanced precision purification. Provide the most advanced, cutting-edge, the most reliable, the top power solutions.
