Controlccircuit Electronic Countdown Multi Range Time Delay Relay with CE
| Price: |
US $ 4.35-7.55/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,Paypal,Money Gram,Western Union |
Product Description
Used to control time sequence
With front / back connecting socket
LED display
Voltage: AC12-240V 50/60Hz DC12-24V
Contact: ST4P-, ST4P-8: Timed 2SPDT H3BA-8H: Timed 1SPDT, Inst. 1SPDT
Operation: Time-limit operation/self-restting/external reseting
Timing Range: (S, M, H, 10H) 0.05-0.5, 0.5-5H, 0.1-1, 1-10H 0.5-5, 5-50H, 1-10, 10-100H
Technique parameter
Type |
H3BA(ST4P) |
Dimensions |
48HX48WX93.5D |
Mounting |
Surface (-N) |
PF113A(E) |
PS-08 |
Socket |
Flush(-Y) |
US-11 |
US-08 P3G-08 |
Full timing range |
0.5SEC~100HRS |
Rated voltage |
24 to 240V DC/AC
DC(V):12,24,48
AC(V):24,50,110,220 |
Indicator operation |
Time operation flicker |
O/P
Contact |
Model |
H3BA |
H3BA-8 |
H3BA-8H |
Time limit 1c |
|
|
5A |
Time limit 2c |
5A |
5A |
|
Instantaneous 1c |
|
|
5A |
Service life |
Mechanical |
5X10000000 times |
Electrical |
100000 times |
Accuracy |
Repeat error |
±2% max |
Setting error |
±5% max |
Voltage error |
±5% max |
Temperature error |
±2% max |
Reset time |
0.5 sec max |
Consumed power |
100~240VAC: 10VA 12VDC,
24~240VDC: 1.5W |
Ambient temperature |
-10~+55 |
Ambient humidity |
35-85% RH |
Weight |
100g |
