Current Transformer (CT101-25A-VB)

Name: Current Transformer (CT101-25A-VB)
Brand: all-electronics-online.com
SKU: 780672745
Availability: InStock
Rating: 4.8 (40 reviews)

Price:	US $ 1/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

current transformer

Features:

Epoxy resin molding encapsulation,good mechanical property and insulation property;extremely high

linearity and stable phase error;meet the standards of IEC60044-1,GB1208-97

Applications:

Electric energy meter,preccision wattmeter,electric quantity transformer,data sampling for current and

voltage,relay protection,power transmitter,servomotor and electric power monitoring facilities,various digital

electrical measuring instruments in dynamic system,meters and intelligent electric control cabinet.

Electrical Parameter		Mechanical Parameter
Frequency	50-400Hz	Case	PBT /UL94-0
Rated Input	0-250A	Bobbin	PBT
Measuring range	5%In-120%In	Core	Permalloy or Nanocrystalline
Rated Output	0-100mA	Internal structure	Epoxy
Ratio	≤± 0.1%	Construction	-----
Phase angle	≤ ±5min	Operating Temp	-25~+75 degree
Dielectric strength	2.5KV/1mA/1min	OperatingHumidity	≤85%
Insulation Resistance	DC500V/1000M Ohm min	Output Connection	Leads

Prod Model:	CT101-25A-VB
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
High Saturation Magnetic Induction:	Low Core Loss
Application:	Lighting
Type:	Current Transformer
Phase:	Single and Three
