| Prod Model: |
XWM |
| Emboss: |
Pillow/Dome/Frame Emboss |
| Rear Adhesive: |
3m467,3m468 |
| Key Option: |
Flate or Tactile Key |
| Type: |
Flexible |
| Material: |
PET |
| Application: |
Camera |
| Structure: |
Overlay+Reaining Layer+Circuit+Rear Adhesive |
| Brand: |
Singway |
Product Description
| Electrical Property |
| Working voltage | working current | contact resistance | Insulation resistance | Base material pressure | Recoil time | Loop resistance | Insulation ink pressure |
| ≤50VDC | ≤100mA | 0.5~10 Ω | ≥100m Ω | 20KDVC | ≤6ms | 50 Ω ,150 Ω ,350 Ω or based on customer's requirement | 100VDC |
| Mechanical Property |
| Working life | Closingdisplacement | Snapping back time | Power standard | The caudal may old |
| >1,000,000 | 0.1~0.4mm(not touch type);0.4~1.0mm | ≤6ms | 15~750g | ≤180° |
| Environmental Performance |
| Operating temperature | Storage temperature | Working humidty | Barometric pressure | Altitude |
| -20°~+70° | -40°~+85° | 95%±5% | 86~106kDa | 0~400m |
| Printing indicators |
| 1,The printing size deviation±0.1mm;Exterior line deviation ±0.1mm. |
| 2,No ink dispersed,no word disability. |
| 3,The color difference is not more than grades two. |
| 4,No crease or paint drop. |
Packing & Delivery
Lead time:
★Lead-time for our company to create and submit counter-drawings + artwork for your approval:2-3 work days
★Lead-time for our company to build tooling and ship the 5 samples for your approval:10 days
★Lead-time for you have approved the 5 samples:2-3 weeks
Packaging Details:
1) Wrap in air bubble film
2) Put into foam box
3) Packed with extra carton box, which make sure the goods safety in transportation.
4) We accepted Customized package.
Shipping Details:
1) Can Ship by express such as DHL, FEDEX, EMS, TNT, UPS, or by Sea, by air, it's depends on your
requirement.(The express shipping time is about 3 to 7 working days.)
2) The tracking number will be informed after 1 day the package delivered.
3) We will follow the shipment after we sent it. If you not receive goods on time, please contact us immediately, we will assist to get the goods smoothly.
Payment terms:
1.First 3 dealings: payment term is Cash On Delivery(C.O.D.), we accept Bank T/T for payment.
2.After the first 3 dealings: payment term is 30 days.
FAQ
FAQ:
1.When can I get the price?
We usually quote within 24 hours after we get your inquiry.
2.Can we make customized products?
Yes, we can manufacture the products as your requirements,and could make products according to your design, draft or samples.
3.How can I get the sample?
We will provide free Membrane Switch sample, freight collect.But for customized samples, it need sample cost and freight collect.
4.What are your lead times?
Generally, 3-5 days for existing samples,1-2weeks for customized samples.
5.What's the payment?
Usually we accept T/T, Western Union, L/C ,Paypal and so on.
