| Prod Model: |
Multilayer PCB-30 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| PP Thickness: |
7628(0.18mm) 2116(0.12mm) 1080(0.08mm) |
| Core Base Board: |
0.3mm 0.5mm 0.6mm 0.8mm 1.0mm |
| Shipment: |
Air,Sea,Express(DHL TNT FedEx EMS UPS) |
| Sample Date: |
5-7days |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
ZHEJIANG ZAPON ELECTRONIC TECHNOLOGY Co., Ltd is a professional manufacture of PCB and PCBA. Which have the factory of single side PCB, double side PCB, multi-layer PCB and PCB assembly etc. We have the ability of produce for any medium and mass quantity. The machine of our factory are on work all day and all night. With Zapon as a supplier, you will have the highest quality, quickest delivery.
The products:
Single-side PCB: CEM-1, FR-2, FR-1 XPC-94HB
Double-side PCB: FR-4, CEM-3, High Tg, Aluminum, Halogen Free
Multi-layer PCB: 4 to 22 layers(FR-4, High Tg, Rogers)
Certification: UL, ISO9001, ISO/TS16949: 2002, IS014001 and RoHS
THE CAPACITY OF PRODUCTION: 50, 000SQM. /month
| | Capabilities |
| Number of Layers | From 4-layer to 22- Layer |
| Material | FR-4,HighTg, Rogers
Halogen Free |
| PCB Thickness | Min.thickness | 0.4mm(16mil) |
| | Max.thickness | 3.2mm(128mil) |
Surface finished | Gold Plating |
| | Immersion Gold(Silver) |
| | HAL Lead Free |
| | Hot Air Solder Leveling(HASL) |
| | Entek Coating (OSP) |
| Solder Mask | Green,White,Black,Yellow,Red,Blue |
| Other printing | Gold Finger |
| | Carbon Print, Peelable Mask |
| | Solder Mask Plugged Hole |
| Copper thickness | 1/ 2 oz (18 μm) - 4 oz (140 μm) |
| Min. Finished Hole Size | 0.2mm(8mil) |
| Hole Size Tolerance (PTH) | +/ -0.076mm (3 mil) |
| Hole Size Tolerance (NPTH) | +/-0.05mm (2 mil) |
| Min. Line Width and Spacing | 0.1mm (4 mil) |
| Min. Solder Mask Clearance | 0.05mm (2 mil) |
| Min. Annular Ring | 0.076mm (3mil) |
| Profile and V-Cut | CNC-Routing, Stamping and Beveling,V-CUT,CNC
|
| Special Process | Micro-section, Chamfer for Gold Finger |
| File format | Gerber file , CAM350 ,Protel,PowerPCB |
| E-TEST | Flying Prob , E-test ,Fixture |
| Other Test | Impedance , Slice up |
| Warp & Twist | ≤0.7% |
Zhejiang Zapon Electronic Technology Co., Ltd is a professional manufacture of Aluminum base PCB and rigid PCB. Which have the factory of Alu base PCB, double side PCB, multi-layer PCB and PCB assembly etc. We have the ability of produce for any medium and mass quantity. The machine of our factory are on work all day and all night. With Zapon as a supplier, you will have the highest quality, quickest delivery. The detail information of our company are in below:
Establishment: 1997
Registered Capital: US$10M
The area of company: 16800m2
The number of staff: 622
Products:
Aluminum base PCB: One side aluminum PCB and double side Alu-PCB
Double-side PCB: FR-4, CEM-3, High Tg, Halogen Free
Multi-layer PCB: 4 to 22 layers(FR-4, High Tg, Rogers)
Certification: UL, ISO9001, ISO/TS16949: 2002, IS014001 and RoHS
THE CAPACITY OF PRODUCTION: 50, 000SQM. /month
All your inquiry of quotation will be replied within 4-hour. Our engineer will be on your service at any time. And your satisfaction is our biggest wish! ! !
Through the efforts of all staffs. Zapon has stood out among PCB company like us and has became a leading company in this industry. We have won accptance and set up a good reputation in domestic and international markets with the competitive price, the perfect atfter-sales services and the wide support of the suppliers. Our main clients in Samsung, Turkey, Italy, England, Portugal, America etc. Our products meet the military and IPC standards and specifications.
We hope we can be your best partner and offer you the best price with good service Do the biggest assistant for you to reduce your cost.
As long as we have the first cooperation, we believe we will get together, we are confident for establishing a long term friendship once our first cooperation made.
