| Prod Model: |
Camera GPS105 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
110*82*28mm |
| Weight: |
220g |
| Warranty Time: |
1 Year |
| Delivery Time: |
1-3 Working Days |
| Certificate: |
CE |
| Shipment: |
DHL, UPS, EMS, TNT, FedEx, Hkpost etc |
| Backup Battery: |
Chargeable Changeable 3.7V 500mAh Li-ion Battery |
| GPS Module: |
Ns1315 |
| GPS Sensitivity: |
-159dBm |
| GPS Accuracy: |
5m |
| Type: |
GPS Tracker |
| Use: |
Automotive |
| Port Number: |
Multiplex Multi-purpose Channel |
| Carrier Frequency: |
Dual-Frequency |
| Chip: |
SiRF |
| Operating Principle: |
GPS Satellite Positioning and Data Transmit by GSM |
| Model: |
Coban GPS 105 |
| Screen Size: |
No Screen |
| Brand: |
Coban |
| Certification: |
CE, FCC |
Product Description
Detailed description
It is based on GSM/GPRS(850/900/1800/1900MHZ)wireless telecommunication internet and GPS satillite global position system,track by multi tracking ways
Basic functions:
1. Tracking by GPS and location base service both even in building, underground and garage
2, Real time tracking via SMS or GPRS (TCP/UDP)
3, Track on demand by calling or sms comamnd
4, Show location directly on mobile phone with HTTP google map link
5, Track by time interval
6, Five authorized phone number to protect tracker information and assets
7, Voice Surveillance
8, Easy switch for track or Monitor
9, SOS button ,Low battery alarm, Geo fence,Overspeed Alarm , Power off alarm
10 Engine -cut and restore alarm by SMS GPRS
11, Door, windows alarm get by SMS
12, Movement alert sensor
13, RFID
14. With direction and heading value
15. Optional vibration sensor and fuel sensor
16. Optional camera
17 Support SD card function
Applying directions:
*Vehicle fleet/logistics/vehicle rental (12 to 24V)
Technology parameter:
| Content | Specifications |
| DIM | 92*71*26mm |
| Network | GSM/GPRS |
| Band | 850/900/1800/1900Mhz |
| GPS Module | NS1315 chip |
| GPS Sensitivity | -159dBm |
| GPS Accuracy | 5m |
| GPS Start Time | Cold status 45s
Warm status 35s
Hot status 1s |
| Applicable vehicle power | 12 V -24V
|
| Backup Battery | Chargeable changeable 3.7V 500mAh Li-ion battery |
| Storage Temp | -40°C to +85°C |
| Operation Temp. | -20°C to +65°C |
| Humidity | 5%--95% non-condensing |
