| Prod Model: |
YJV YJV22 |
| High Voltage Cable Conductor: |
Copper |
| High Voltage Cable Sectional Areas: |
150mm2 |
| High Voltage Cable Outer Sheath: |
Polyethylene |
| Cable Voltage: |
10kv-35kv |
| Cable Standard: |
IEC60332 |
| Cable Sectional Area: |
1.5mm2-16mm2 |
| Cable Packing: |
Plastic Reel |
| Application: |
Car |
| Voltage: |
High Voltage Cable |
| Current: |
DC & AC |
| Insulation Material: |
XLPE |
| Certification: |
CCC |
| Brand: |
Upward |
Product Description
Parameters of high-voltage cable
High-voltage cable is a kind of power cable and means the power cable for transmitting the voltage within 10KV-35KV (1KV=1000V), and is mostly applied in the main road of power transmission. The executive standards of high-voltage cable product are GB/T 12706.2-2008 and GB/T 12706.3-2008.
Detailed description
Conductor: Copper or aluminum
Insulation: Cross-linked polyethylene
Filler: Filler strip
Packaging: Wood shaft or packaging bag, depending on your requirement
Outer sheath:
Armoring: Fine steel wire armoring or steel tape armoring
Service characteristics of high-voltage cable: This product is applicable to the fixed laying lines for power supply, transmission and distribution with AC rated voltage of 35KV and below. The maximum long-time operating temperature of cable conductor is 90ºC, and in case of short circuit (not exceeding 5S at most), the maximum temperature of cable conductor is not greater than 250ºC.
Standard sectional areas: 25mm2, 35mm2, 50mm2, 70mm2, 95mm2, 120mm2, 150mm2, 185mm2, 240mm2, 300mm2, 400mm2.
| Type | Name | Application |
YJV
YJLV | Cross-linked polyethylene-insulated, PVC-sheathed power cable
Cross-linked polyethylene-insulated, PVC-sheathed aluminum power cable | Overhead, indoors, tunnel, cable trench |
YJV22
YJLV22 | Cross-linked polyethylene-insulated, steel tape-armored, PVC-sheathed power cable
Cross-linked polyethylene-insulated, steel tape-armored, PVC-sheathed aluminum power cable | Indoors, tunnel, cable trench and underground |
YJV32
YJLV32 | Cross-linked polyethylene-insulated, fine steel wire-armored, PVC-sheathed power cable
Cross-linked polyethylene-insulated, fine steel wire-armored, PVC-sheathed aluminum power cable | High drop, vertical shaft and underwater |
| Note: Add ZC to the original model of flame-retardant cable of the Company, NH to fire-resistant cable, and WDZN to low-smoke, halogen-free, flame-retardant and fire-resistant cable. |
