Highlights of Voltage Stabilizer or Voltage Regulator
| Price: |
US $ 1450-1625/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Paypal |
Highlights of Voltage Stabilizer or Voltage Regulator
| Model | output voltage | input voltage | output channel | MEAS | NW(kg) |
| MZDC-302 | 0-30V | 0-2A | single channel | 310x135x170 | 5 |
| MZDC-303 | 0-3A | 310x135x170 | 5.5 |
| MZDC-305 | 0-5A | 310x135x170 | 6 |
| MZDC-3010 | 0-10A | 325x260x170 | 10.2 |
| MZDC-3020 | 0-20A | 325x260x170 | 17.8 |
| MZDC-302B2 | 0-30V | 0-2A | two-channel | 370x260x170 | 9.5 |
| MZDC-303B2 | 0-3A | 370x260x170 | 9.5 |
| MZDC-305B2 | 0-5A | 420x260x270 | 11 |
| MZDC-3010B2 | 0-10A | 490x265x170 | 20.4 |
| MZDC-503 | 0-50V | 0-3A | single channel | 370x260x170 | 6 |
| MZDC-505 | 0-5A | 370x260x170 | 7.5 |
| MZDC-603 | 0-60V | 0-3A | 370x260x170 | 6.5 |
| MZDC-605 | 0-5A | 370x260x170 | 8.5 |
| MZDC-503B2 | 0-50V | 0-3A | two-channel | 490x265x220 | 11.5 |
| MZDC-505B2 | 0-5A | 490x265x220 | 13 |
| MZDC-603B2 | 0-60V | 0-3A | 490x265x220 | 13.2 |
| MZDC-605B2 | 0-5A | 490x265x220 | 15.5 |
| MZDC-1002 | 0-100V | 0-2A | single channel | 450x265x220 | 11 |
| MZDC-1003 | 0-3A | 450x265x220 | 13 |
| MZDC-1005 | 0-5A | 450x265x220 | 14 |
| MZDC-1502 | 0-150V | 0-2A | 450x265x220 | 12.5 |
| MZDC-1503 | 0-3A | 450x265x220 | 14.5 |
| MZDC-1505 | 0-5A | 450x265x220 | 17 |
| MZDC-3001 | 0-300V | 0-1A | 520x265x220 | 16 |
| MZDC-3002 | 0-2A | 520x265x220 | 19.4 |
| MZDC-3003 | 0-3A | 520x265x220 | 20.7 |
| MZDC-302B4 | 0-30V | 0-2A | two-channel | 460x343x200 | 18.8 |
| MZDC-303B4 | 0-3A | 460x343x200 | 19.5 |
| MZDC-305B5 | 0-5A | 460x343x200 | 22.5 |
| MZDC-505B4 | 0-50V | 0-5A | 460x343x200 | 30.5 |
MZDC SERIES is Dc regulated power supply circuit for linear series adjustment type structure, with the advantages of high stability, low ripple voltage. Using voltage suspension type technology, Output voltage can be transferred to the rating from zero volts, Output current can range from zero amps preset to the rating.Adopt SCR or relay preliminary stability change on both ends of the voltage rectifier bridgeDual power supply, with functions of master-slave track series and parallel. when cascade used, , The output voltage is equal to the double power source voltage, Increase the load voltage, When using parallel output current is the sum of two lines of output current Increase the load currentSmall volume, light weight, convenient adjustment, high precision, low ripple voltage, output voltage and current are starting from zero, with functions of master-slave track.The input voltage: 220V±15% 50±1HzThe output voltage: Can be adjusted according to the demand o f 0 ~ maximum ratingOutput current: Can be adjusted according to the demand of 0 ~ maximum ratingEffect of the power: 5x10 +10mvCurrent effect: 5x10 +15mvRipple voltage: Vp-p 10mv
1. Welcome your enquiryContact me :leon liang Mob:+86 18824648626
| Prod Model: |
MZDC SERIES |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Current Type: |
DC |
| Phase: |
Single Phase |
| Usage: |
DBW |
| Frequency: |
Low Frequency |
| Size: |
Small Large |
| Application Range: |
Hotel School Railway |
| Brand: |
Meze |
Meze company was founded in 1999, so far, has developed into a comprehensive power supply enterprise, products include: UPS uninterruptible power supply, microcomputer non-contact electronic AC regulated power supply, EPS emergency power supply, etc. Main range: The financial, government, research institutes, transportation, aerospace, electronics, medical, services, etc. To meet the global electronic and communication industry for power equipment is increasingly vigorous market demand, Due to the need of development, shenzhen Meze power technology Co., Ltd was established in 2008 (Specialize in UPS power frequency, regulated power supply, and transformer) In the same year registered Meze electronics Co., Ltd. (Terminal blocks, all accessories of PCB), In 2011, registered shenzhen Meze mechanical and electrical Co., Ltd. ( SMT placement machine and accessories ).
Existing number of employees: 180-180 employees, Using area: 3000 square meters, Company has the high technology and rich experience, Products from well-known international brands of Europe, is committed to providing customers with the full range of high quality high performance high stable power supply protection. Using the international advanced intelligent digital UPS power supply technology, and the most advanced precision purification. Provide the most advanced, cutting-edge, the most reliable, the top power solutions.
