Indoor Constant Current LED Power Supply 50W 2100mA

Name: Indoor Constant Current LED Power Supply 50W 2100mA
Brand: all-electronics-online.com
SKU: 814358825
Availability: InStock
Rating: 4.7 (43 reviews)

Price:	US $ 11.6-15/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Indoor Constant Current LED Power Supply 50W 2100mA

PLD050-1SCF55-2100 offers constant current drivers with wide-range dimmable output
current and 90~305Vac universal input.
The output current of this series is up to 2.1A , and designed for Indoor applications

Applications
Indoor LED lights
Downlights, spotlights, LED panels

Features
100,000 hours lifetime at 65oC Tcase
5 years warranty at 50oC Tcase
Constant current output
Universal input voltage: 90~305Vac
Safety according to UL8750 &EN61347-2-13
EMC according to FCC Part 15 Class B
Lightning, OVP, SCP, & Open Circuit Protection

Electrical Specifications

Model	PLD050-1SCF55-2100
Output Voltage	16~24V
Output Current	2100mA
Output Power	50W
Max. Current Ripple	±30%
Voltage Range	90~305Vac
Frequency Range	47~63Hz
Max. Input Current @ 230Vac	0.75A
Max. Input Power	60W
Power Factor	>0.95 @ 115Vac & 80~100% load, >0.90 @ 277Vac & 80~100% load
Efficiency	87%
Max. Open Circuit Voltage	70V
THD	<20% @ 120Vac & 80~100% load
Protections	OVP, OTP, OCP, SCP
Environmental Protection	UL Dry & Damp
Working Temperature	-20~+60oC
Max. Case Temperature	90oC
Surge Protection	1kV
Agency Approbations	UL8750
Electromagnetic Compliance	Per Title 47 CFR Part 15 Class B
Ansi Surge Type	1.2/50μs Combination Wave (w/t 2Ω)
Isolation	Primary to Secondary: 3750Vac / 10mAMax / 60seconds
Dimension	95x70x32 mm (3.74x2.76x1.26 inch)
Mounting Length	85 mm (3.35 inch)
Overall Length	95 mm (3.74 inch)
Weight	0.34 kg (0.75 lb)
Life Time	100,000 hours @ full load, 65oC Tcase

* Unless otherwise noted, the data are based on 25oC ambient temperature, 230Vac input voltage, and full load.

Prod Model:	PLD050-1SCF55-2100
Output Power:	50W
Usage:	Construction
Output Type:	Single
Driving Method:	LED Constant Current
Circuit Structure:	PWM Controlled
Power Supply Voltage:	90~305VAC
Pack Sealing Size:	95X70X32 mm
Brand:	Fsp-Powerland
