Knob / Mouse Control Android Navigation Interface Two-in-one Unit for 2014-2017 Lexus ES
Overview
Android auto interface allows to connect external video sources, such as android navigation box , front rearview camera , camera , 360 round view cameras , DVR , mobile phone mirrorlink , DVB-2 module , DVD module etc . Through auto interface,all video source which you installed can be played on car's screen .
Compatible Models
2014-2017 Lexus ES / NX / RX / LS / IS / LX
Basic Functions :
1.Online and offline map
2. Apps Download . Youtube , Facebook, Gmail, Google play etc .
3. Mobile phone Mirrorlink
4. Support to connect rear view & front view cameras , DVR, 360 bird view cameras , TV box, TPMS optional.
5. Enable to connect WIFI by hotpot sharing from smartphone
6. Enable to play USB source
Special Futures
1. Support to upgrade app and mcu online by Cloud
2. Enable to control Android system by Factory Knob
3. Sounds and picture can be switched at the same time
4. Come with 2 Video Inputs
5. Support Front camera , Rear Camera , Left-side camera , right-side camera optional
6. Enable to start Android system in 1s .
7. Support resistive touch and capacitive touch at the same time
8. Support to activate side cameras by steering wheel or turn light
9. Navigation sounds come from factory speaker
10. Full plug and play
11. Friendly Design
Product description :
1.Supports external video source input,full touch screen, Android operating system;
2. Multiple Switching ways:press and hold on the screen, 2 fingers sliding, third party device control,etc;
3. Full-digital circuit, LVDS signal processing, achieve high-definition images;
4. Navigation voice optional (the original car/separate speakers).Input all voice into the original car audio system! Achieve perfect sound;
5. Support trajectory reverse, Support front video input. You can choose to install 360 bird's eye view panorams, truly achieve parking without blind area;
6. It's convenient for drivers and passengers to enjoy different entertainment programs since the foreground-background work independently;
7. Optional external RGB (800 x480) input,Andrews system connection,HD display;
8. UI of the original car UI,matching the original car style,integrated the original car system;
9. Full pull-in installation,realize nondestructive installation;
Product list:
1* Android navigation interface two-in-one unit
1* speaker
1* Microphone
1* GPS Antenna
1* map card
Touch screen as optional
All necessary cables
Specifications:
Master processor: RK3188T Quad-Core Processor (RK 3188T/RK 3188/PX3) basic frequency is 1.6G.
Memory capacity: 2G DDRIII optional.
Flash memory: 16G.
OS: Android 6.0
GPS receive: support AGPS function
GPS antenna: 3V active antenna
GPS antenna protection: prevent the antenna short circuit
WiFi module: RTL8188 / RTL8723.
BT module: RTL8723BU,support BT4.0, firmware support Bluetooth functions.
A2DP,Bluetooth telephone.
Support USB 3G dongle,WiFi can be as a hot spot output.
Synchronizing signal: composite synchronizing signal. Separate sync signal.
Video output format: simulate RGB and CVBS composite synchronizing signal output , one of them optional.
Analog video output: Support the display position adjustment,and brightness contrast adjustment.
The resolution of the video output: 800×480,1024X600,Maximum 1920X1080, Support any resolution.
Audio output: Left and right channel stereo output with audio valid indication signal.
Sound Control output: IO output or UART output.
Single track MIC input: support voice navigation, support SPDIF output.
Touchscreen interface: Support 4-wire resistive touch (support two point touch function), support serial touch, two ways to touch without modifying the hardware. Change software will be ok.
Memory card types: support maximum 64 gb TF/SD card, support read U disk, mobile hard disk storage.
USB port : USB OTG 2.0 .
Supported map software: APK install automatically or installation package .
Voltage range: 7 ~ 16v (optional 9 ~ 28V), with undervoltage shutdown (7V protection shutdown).
ACC control: ACC support delay shutdown, and SLEEP combination can be set off at any time. | |
| | |
Quality warranty policy:
3 month free replacement and 1 year free maintenance due to product problem .
Send goods in 1 or 2 days after full payment received.
Customer service department will contact with you by whatsapp, email, skype for after-sale service . |
| MAP (GPS Navigation) |
| Supportable navigation software | Beauty line,DaoDaoTong,LingTu, hypergraph,NaviOne,AutoNavi,baidu,Google,IGO,SYGIC |
| Map Upgrading | Through TF card |
| | Support 3D live navigation,(Need navigation software to support) |
| | Support navigation sound mixing/sound sent back |
| | Support real-time traffic(Need navigation software to support,internet) |
| | Support multiple navigation software |
