| Prod Model: |
HTW-31-WT26 |
| Thermostat Operating Voltage: |
2 X AA1.5 V, Alkaline Batteries. |
| Backup Storage: |
Eeprom |
| Receiver Operating Voltage: |
230 VAC, 50/60 Hz |
| Maximum Voltage / (Ohmic) Load: |
250 VAC/10 a. |
| Frequency: |
868 MHz/433MHz Optional |
| Channel Selection: |
by Programming The Thermostat and The Receiver |
| Switching Options: |
Non Programmable |
| Receiver Switch Contacts: |
No and Nc. |
| Temperature Settings: |
5°c ~ 35°c, 0.5°c Increments. |
| Accuracy: |
+/- 0.5°c |
Product Description
GeneralNon Programmable Digital Radio RF Underfloor Heating Wireless Thermostat(HTW-31-WT26) series are used to control the water heating system or electric underfloor heating system in industrial, commercial and residential environments.
This wireless thermostat consists of an transmitter and receiver. Through wireless data communication between thermostat and controller, with controlling signal and code sent, received and executed on the purpose of temperature controlling on personal requirement.Features• Gas Boiler/Water heating system/Electric heating system
• Communicates at 868/433 MHz optional for stand-alone interface
• Transmits up to Beeline distance 100m in the field (The distance will shorten if through walls and floors)
• Easy Installation
• Non-programmable
• OEM Service
Technical Parameters• Power method: 2xAA1.5V
• Thermostat Dimensions (mm):112mm x 86mm x 22.7mm.
• Controller Dimensions(mm): 86mm x 86 mm x23mm
• Setting temperature range: 5°C to 35°C
• Differential Temperature: ±0.5°C
• Thermostat Color: white
• Temperature Sensor: NTC Thermistor
• Transmitter Frequency: 868/433MHz optional
• Operation Humidity Range:5~95%RH(non-condensing)
• Controller Voltage: 230Vac
• Controller Power Frequency: 50/60Hz
• Mounting: Surface mounting
Display
Q1:What is the unit price?
A.:The unit price varies according to different specific requirements, we are more than pleased to quote you the best price once
get your specific application. e.g. W/O Modbus, W/O key-card, 2/4 pipe system, W/O customized programming...
Anyway, we are always ready to discuss details with you via Email.
Q2:What is the MOQ, small quantities accetaple?
A.: Commonly the MOQ for us is 500pcs, however, we also accept small quantities or Sample orders as starting.
Q3:How is your products' quality and warrenty?
A.:All of our products meet EU standards, samples are available for quality evaluation; all products are with 18 months warrenty.
Q4:Can I print my logo on the products, and customize my own designed packing?
A.:100% YES, but the order quantity shall be over MOQ, or else, extra costs will be charged.
Q5:Do you supply OEM or ODM?
A.:Yes, we have strong R&D sources and production ability, and already helping many international companies OEM/ODM cases with highly positive feedback.
Q6:Why should I buy products from your company?
A.:That's really a good question, Quality Products but with Competitive Price, Timely Delivery, Professional and Fast Reacton, ...
In a word, WE ARE DIFFERENT, why not just try from the Email...
HOTOWELL International Co., Limited is an innovative and modern medium-sized enterprise, the company is headquartered in Xiamen (China/Fujian). Hotowell was found to offer our customers mature top technology. Our creative potential and our manufacturing and development know how are the basis for innovative products. Since the company was founded, HOTOWELL International Co., Limited has continuously developed itself into a market leading enterprise in the HVAC Automation / Building Automation. Our products mainly applied for industrial, commercial and residential temperature control.
Our product range contains:
Thermostats, Motorized Zone Valves, Water Flow Switches, Proportional Valves, Balancing Valves, Differential Pressure Transmitters, PIR Motion Sensors, Fan Controllers, Ball Valves, Valve Actuators, Damper Actuators, Controllers, Radiator valves, and etc.
HOTOWELL products are designed and used as field control products to be integrated with HVAC control systems such as:
BAS = Building Automation System
BMS = Building Management System
BEMS = Building Energy Management System
BAMS = Building Automation Management Systems
HVAC controls = Heating, Ventilation and Air Conditioning controls
Our objective is to develop, produce and design user-friendly products on the highest technical level. We place great value on always meeting the requirements of the latest technical standard. In this process we take the utmost care in complying with quality and safety standards and thus ensure a long service life for our products. Products that satisfy rigorous quality requirements can only be manufactured through modern manufacturing methods. Satisfaction of all safety and environmental guidelines is a matter of course for us.
Our Products save money and protect the environment!
*********************************************************************************************************
