O3 SO2 NO2 CO Cl2 Br2 CH2O ETO Alc CO H2 H2O2 H2S HCl HBr HCN NH3 NO PH3 SiH4 O2 Gas Sensor Detector with Transmitter Board

Name: O3 SO2 NO2 CO Cl2 Br2 CH2O ETO Alc CO H2 H2O2 H2S HCl HBr HCN NH3 NO PH3 SiH4 O2 Gas Sensor Detector with Transmitter Board
Brand: all-electronics-online.com
SKU: 836683345
Availability: InStock
Rating: 4.6 (65 reviews)

Price:	US $ 6-366/Piece
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Gas Module Introduction
FAD gas module with two/three wire TTL/0-20mA/RS485 output, integrates toxic gas sensor + transmitter board. Adopting imported advanced electrochemical gas sensors, it has features of high accuracy, long lifetime, high stability and high anti-interference. The module is designed to prevent circuit reversed connection, high voltage, high current and lightning

Gas Module Feature

- Long lifetime imported advanced electrochemical sensors

- High accuracy op ams, power supply IC, stable and sensitive

- Detect low or high concentration toxic gases precisely

- High anti-interference ability

- Over range protection, reversed polarity protection and lightning protection

- Low power consumption with a standard 4-20mA two/three-wire signal output

- Interface: pump, diffusing, flange, flange thread types

- 12-36VDC operating voltage

O3 Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-5	O3/M-5	O3/C-5	O3/S-5-S
0-100	O3/M-100	O3/C-100
0-200		O3/C-200
0-1000		O3/C-1000
0-5000		O3/C-5000
0-30000				O3/S-30000

Cl2 Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-20	Cl2/M-20	Cl2/C-20	Cl2/S-20-S	Cl2/S-20
0-50			Cl2/S-50-S	Cl2/S-50
0-200	Cl2/M-200	Cl2/C-200	Cl2/S-200-S	Cl2/S-200
0-2000		Cl2/C-2000
0-5000		Cl2/C-5000

Alc Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact
0-100		Alc/C-100
0-200	Alc/M-200

H2 Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-1000	H2/M-1000	H2/CA-1000 H2/CB-1000	H2/SA-1000-S	H2/SA-1000
0-2000		H2/C-2000	H2/S-2000-S	H2/S-2000
0-4000	H2/M-4000
0-5000		H2/C-5000
0-10000		H2/CT-10000	H2/S-10000-S
0-20000		H2/C-20000	H2/SA-20000-S
0-40000	H2/M-40000	H2/C-40000 H2/CT-40000

H2O2 Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact
0-100	H2O2/MB-100	H2O2/CB-100
0-500	H2O2/MB-500	H2O2/CB-500
0-2000		H2O2/CB-2000

HCl Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact
0-20 ppm	HCl/M-20	HCl/C-20
0-20 ppm	HCl/M-200	HCl/C-200
0-1000 ppm		HCl/C-1000
0-3000 ppm		HCl/C-3000

HCN Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-50 ppm	HCN/M-50
0-100 ppm	HCN/M-100	HCN/C-100	HCN/S-100-S	HCN/S-100

O2 Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-50 ppm	HCN/M-50
0-100 ppm	HCN/M-100	HCN/C-100	HCN/S-100-S	HCN/S-100

PH3 Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-5 ppm	PH3/M-5	PH3/C-5	PH3/S-5-S	PH3/S-5
0-20 ppm	PH3/M-20
0-200 ppm	PH3/M-200
0-500 ppm		PH3/C-500
0-1000 ppm		PH3/C-1000
0-2000 ppm	PH3/M-2000	PH3/C-2000
0-4000 ppm		PH3/C-4000

NO2 Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-1 ppm		NO2/C-1
0-20 ppm	NO2/M-20	NO2/C-20	NO2/S-20-S
0-100 ppm	NO2/M-100			NO2/S-100
0-500 ppm	NO2/M-500	NO2/C-500	NO2/S-500-S
0-1000 ppm			NO2/S-1000-S	NO2/S-1000
0-2000 ppm			NO2/S-2000-S
0-5000 ppm			NO2/S-5000-S

CH2O Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-10	CH2O/M-10 CH2O/M-10-2E	CH2O/C-10		CH2O/C-10
0-50	CH2O/M-50
0-1000	CH2O/M-1000	CH2O/C-1000

SiH4Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-50 ppm	SiH4/M-50	SiH4/C-50	SiH4/S-50-S	SiH4/S-50

SO2 Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-1		SO2/C-1
0-20	SO2/M-20 SO2-M-2E SO2/MF-20	SO2/C-20 SO2/CF-20	SO2/S-20-S	SO2/S-20
0-100	SO2/M-100-2E SO2/MF-100	SO2/C-100 SO2/CF-100	SO2/SF-100-S	SO2/S-20 SO2/SF-20
0-200	SO2/MF-200
0-400			SO2/SF-400-S
0-1000	SO2/MF-1000
0-2000	SO2/MF-2000	SO2/C-2000 SO/CF-2000	SO2/S-2000-S SO2/SF-2000-S
0-10000	SO2/MF-10000	SO2/CF-10000	SO2/SF-10000-S

H2S Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-10 ppm		H2S/C-10		H2S/S-50 H2S/SP-50
0-50 ppm	H2S/M-50	H2S/C-50	H2S/S-50-S
0-100 ppm	H2S/M-100	H2S/CG-100-4E H2S/CP-100
0-200 ppm	H2S/M-200-2E	H2S/C-200	H2S/SG-200-S	H2S/S-200
0-500 ppm	H2S/M-500	H2S/C-500 H2S/CP-500
0-1000 ppm		H2S/C-1000		H2S/S-1000 H2S/SP-1000
0-2000 ppm	H2S/M-2000	H2S/C-2000 H2S/CG-2000 H2S/CP-2000	H2S/SG-2000-S
0-5000 ppm		H2S/C-5000 H2S/CP-5000		H2S/S-5000
0-10000 ppm		H2S/CP-10000	H2S/S-10000-S	H2S/S-10000 H2S/SP-10000

C2H4 Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-10	C2H4/M-10	C2H4/C-10	C2H4/S-10-S	C2H4/S-10
0-200	C2H4/M-200	C2H4/C-200	C2H4/S-200-S	C2H4/S-200
0-1500	C2H4/M-1500	C2H4/C-1500	C2H4/S-1500-S	C2H4/S-1500

ETO Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact
0-10	ETO/M-10
0-20	ETO/M-20	ETO/C-20
0-100	ETO/M-100	ETO/C-100
0-500	ETO/M-500
0-1000	ETO/M-1000	ETO/C-1000
0-50000		ETO/C-5000

CO Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-200	CO/MF-200	CO/C-200 CO/CF-200 CO/CF-200-4E CO/CFA-200	CO/SF-200-S CO/SF-200-4E-S CO/SFA-200-S	CO/SF-200 CO/SF-SFA-200
0-500	CO/MF-500 CO/MFA-500	CO/CF-500 CO/CFA-500	CO/SF-500-S	CO/SF-500
0-1000	CO/MF-1000	CO/C-1000 CO/CF-1000 CO/CFA-1000	CO/S-1000-S CO/SF-1000-S CO/SFA-1000-S	CO/S-1000 CO/SF-1000 CO/SFA-1000
0-2000	CO/MF-2000	CO/CF-2000 CO/CF-2000-4E	CO/SF-2000-S CO/SF-2000-4E-S CO/SGF-2000-4E-S	CO/SF-2000
0-4000		CO/CF-4000	CO/SF-4000-S	CO/SF-4000
0-5000		CO/CFA-5000
0-10000		CO/CF-10000-4E CO/CFA-10000	CO/SF-10000-4E-S CO/SFA-10000-4E-S	CO/SFA-10000
0-40000		CO/CF-40000	CO/SF-40000-S

NO Sensor Detecting Range Selection

Detecting range (ppm)/Size	Miniature	Compact	Slim	Standard
0-1		NO/C-1
0-25	NO/M-25	NO/C-25	NO/S-25-S	NO/S-25
0-100		NO/C-100 NO/CF-100	NO/S-100-S NO/SF-100-S	NO/S-100 NO/SF-100
0-200			NO/SF-200-S
0-250	NO/M-250
0-1000	NO/M-1000		NO/SF-1000-S	NO/S-1000
0-2000		NO/CF-2000	NO/SGF-2000-S
0-5000			NO/SF-5000-S	NO/S-5000

NH3 Sensor Detecting Range Selection

Detecting range(ppm)/Size	Miniature	Compact	Slim	Standard
0-50		NH3/CR-50
0-100	NH3/MR-100 NH3/MR-100-2E
0-200		NH3/CR-200	NH3/SR-200-S	NH3/SR-200
0-500	NH3/MR-500
0-1000	NH3/MR-1000 NH3/MR-1000-2E	NH3/CR-1000	NH3/SR-1000-S	NH3/SR-1000
0-2000	NH3/MR-2000
0-5000	NH3/MR-5000	NH3/CR-5000
0-10000	NH3/MR-10000	NH3/CR-10000

Module Parameters

Module type	GM-I2(3)-M/C/S--**/G/P/F/FL
Detected gas	Toxic gas
Detecting principle	Electrochemistry
Sampling	Diffusing pump flange thread
Responding time	30s~40s(of the sensor)
Module accuracy	≤±3%FS(actual concentration, higher accuracy depends on specified sensors)
Module repeatability	≤±2% FS
Module linear error	≤±2% FS
Module zero temperature drift	≤±2% (FS/year)
Module operating temperature	-40~80°C
Module humidity	0-95%RH(non-condensation)
Sensor operating temperature	-20°C~50°C
Sensor humidity	0-90%RH(non-condensation)
Signal output	TTL/4-20mA /RS485 (two or three wire)
Transmitting distance	1000 meters(RS485)
Operating voltage	DC 12-36V
Maximum power	≤0.8W
Size	80*48mm
Explosion proof	Intrinsic safe
Connection cable	RVVP3 x 1.5mm²

Module applications
Petroleum, petrochemical, metallurgy, chemical, electricity, telecom, gas, mining, pharmacy, municipal wastewater treatment, indoor environment, atmospheric environmental protection, transit equipment, transportation facilities, tunnel safety and underground parking, leak detection, safety and environmental control

Prod Model:	Gas-range
Output:	TTL/4-20mA/RS485
Transmitter Board:	Integrated/Seperated
Wire:	Two or Three Wire
Detecting Range:	Selectable
After Sale Service:	Yes
Material:	PC

Company introduction

Advanced Sensors Application Technology Co., Ltd. Was established on 2003. We are passionate about delivering high quality gas sensor products to our customers. Focus on customized manufacturing, we supply widely to many key industries through our diverse and state-of-art facilities. We have a technician team to support in material designs and testing to international standards meeting customers' requirements.

Products are widely used in petroleum, petrochemical, metallurgy, chemical, electricity, telecom, gas, mining, pharmacy, municipal wastewater treatment, indoor environment, atmospheric environmental protection, transit equipment, transportation facilities, tunnel safety and underground parking.
