Quick Details Place of Origin:Zhejiang, China (Mainland) Brand Name:OMCH Model Number:HE3F series
Usage: Position Sensor Theory: Inductance Sensor Output Switching Transducer
Certification:CE ROHS Dimension:M18x1 Packaging & DeliveryPackaging Details The photo sensor switch will be packaged in carton box or as requried by buyer
Delivery Time Shipped in 15 days after paymentoptical sensors distance photoelectric sensor
Product Descriptio
Power supply reversal connection protection; short-circuit protection, can directly connect with PLC
Used in common places witch medium environment resistance
Red LED indicates that it's available to detect the sensor operating state
IP67 protection structure (IEC specification)
Read the "Matters needing attention" of the Product Instruction before use
Relay is suitable for small electronic control equipment,household appliances
office automation ,test,security and commercial machinery,general equipment,automobile
Machine tools,construction,transportation equipment,instruments and meters,
can be used as a remote control center conversion or enlarge the original.
Dimension | M30 |
Mounting way | Non-Screen shield type |
TYPE | DC
TYPE | NPN | NO | ALJ30A3-15-Z/N1 |
NC | ALJ30A3-15-Z/N2 |
NO+NC | ALJ30A3-15-Z/N3 |
PNP | NO | ALJ30A3-15-Z/P1 |
NC | ALJ30A3-15-Z/P2 |
NO+NC | ALJ30A3-15-Z/P3 |
Two Wire | NO | ALJ30A3-15-Z/D1 |
NC | ALJ30A3-15-Z/D2 |
AC
TYPE | Two Wire | NO | ALJ30A3-15-J/A1 |
NC | ALJ30A3-15-J/A2 |
3 wire | NO+NC | ALJ30A3-15-J/A3 |
Set distance | 15 mm+/-10% |
Standard detection object | 0~13mm |
Response frequency | Iron54*54*1 |
Response frequency | DC:>=0.5kHz AC:50Hz |
DelP2 distance: | 10% below of the detection distance |
Detection object | Magnetic metal (the detection distance decreases when it is non-magnetic metal) |
Supply voltage | DC type: DC12-24V(6-36V) Impulse(p-p) 10% below
Ac type: AC110-220V (36-250V) 50/60Hz |
Consumption current | N.P type:13mA below D type:0.8mA below A type:1.7mA below |
Control output | N.P type:300 mA below D type:200mA below A type:400mA below |
Loop protection | N.P.D type: reversal connection protection, surge absorption, load short-circuit protection
A type: surge absorption |
Ambient temperature humidity | During operation,storage: individually-30~+65(No freeze,no drew),
During operation,storage: Individually35~95%RH |
Insulation resistance | 50 MΩ about(DC500 megameter) between charging and housing |
Withstand voltage | AC1000V50/60Hz 1 min between charging and housing |
Temperature influence | Temperature range-30~+65,at+23,+/-15% detection distance
Temperature range-25~+60,at+23,+/-10% detection distance |
Voltage influence | Inside+/-15%rated supply voltage range, at rated supply voltage value;
Inside +/-10% detection distance |
Protection structure | IP65 ICE specification |
material | Housing: Nickel plated brass; Detection surface: ABS |
| < Proximity Sensor Switch > | < Photo Sensor Switch > | < Solid State Relay > |
| < Capacitive Sensor Switch > | < Color Mark Sensor > | < Rotary Encoder > |
| < Magnetic Sensor Switch > | < Switch Power Supply > | < Temp Controller > |
| < Hall Sensor Switch > | < Mini Relay > | < More > |
Packaging & Shipping
FAQ
1. Q: What certifications do you get?
A: We have CE RoHS, etc.
2. Q: Do you provide guarantee for the goods?
A: Yes, and all goods are offered 1year quality guarantee.
3. Q: Are OEM&ODM available?
4. Q: How to pay?
A: T/T and west union are acceptable.
5. Q: What is the delivery time?
A: It depends on the order quantity and the season you place the order. Generally, 5 to 10 working days after the payment.
6. Q: What about the Package?
A: Standard export package (paper carton) for shipment, or package as you need.
