quick details:
Place of origin: Zhejiang, China
brand name: as per customers' requirements
model number: can be ordered
type: insulating ceramics
material: porcelain
application: high voltage
specification:
Product Description
Porcelain Post Spool Insulator ANSI 53-2
Porcelain Insulator include pin type insulator , suspension type ,post type insulator
Porcelain Post Spool Insulator ANSI 53-2 Specification
ANSI
CLASS |
Fig
No |
Main Dimensions
mm |
Transverse
Strength
kN |
Low Freuqency Voltage kV |
| Dry Flashover | Wet Flashover |
| H | h | D | d | d1 | d2 | R | Vertical | Horizontal |
| 53-1 | 2 | 54 | 27 | 57 | 45 | 18 | 22 | 11 | 9 | 20 | 8 | 10 |
| 53-2 | 1 | 76 | 38 | 79 | 45 | 18 | 24 | 18 | 13 | 25 | 12 | 15 |
| 53-3 | 2 | 81 | 40.5 | 76 | 45 | 18 | 24 | 11 | 18 | 25 | 12 | 15 |
| 53-4 | 2 | 76 | 38 | 105 | 73 | 18 | 24 | 16 | 20 | 25 | 12 | 15 |
| 53-5 | 3 | 105 | 52.5 | 102 | 73 | 18 | 24 | 11 | 27 | 35 | 18 | 25 |
Porcelain Post Spool Insulator ANSI 53-2 advantage
1.20 years global leading profession manufacture of insulator
2.High quality porcelain material
3.Test data: each products will test by QC
4.Fast delivery : you will get the order when you need it
6.OEM is warmly welcome
7.3 line assemble line automatic machine ,
8.Convenient : 45 minutes to wenzhou airport
Porcelain Post Spool Insulator ANSI 53-2 function
1.Small volume, light weight,
2.easy maintenance; easy to install;
3.high mechanical strength, not easy to be broken;
4.excellent seismic performance,
5.good anti pollution performance; high quality stability.
Our products have being in service on electrical networks of more than more than 20 countries from 2005.
We had supplied our products and services to the below customers:
CHINESE STATE GRID,KENYA KPLC & REA,UGANDA REA & UMEME,TANZANIA TANESCO,GHANA ECG,SOUTH AFRICA ESKOM & ARB,NIGERIAL NEPA,COTE D'IVOIRE CI-ENERGIES,JORDAN EDCO & NEPCO,OMAN PDO,VIETNAM EVN,MEXICO IUSA,ECUADOR CELEC,NEPAL NEA,
......….
Here, We look forward to your joining.
Our factory had obtained ISO9001, ISO14001, OHSAS 18001, and almost of our products had been tested by CNAS certificated Laboratory, for example KEMA, Chinese National Lab, and etc
What can we do for you?
1) Good quality guarantee (2 years).
2) Competitive Price (Factory direct price).
3) Agent service in all the world.
4) On time delivery .
5) We offer sample for free.
6) Professional Technology .
7) Quality Control through the whole Manufacturing process.
a. Check the material before the production .
b. Have the random inspection during the production .
c. Make the 100% inspection before the shipment
Zhejiang Lawrence Electric Co., Ltd (referred as L&R) is located in Zhejiang China. It is composed by some branch companies, we also invested some domestic and foreign EPC projects.
L&R has possessed one of the major suppliers in the power and electrical fields for electrical
Projects in the world. Almost all products manufactured by the L&R members have been certified
By KEMA, CE, SGS and CNAS approved Lab.
L&R have been supplying Zinc Oxide Varistors, Surge Arresters, insulators, Fuse Cutouts, Air
Break switch, Load break switch, Vacuum Circuit Breaker, Isolators, Transformers, Switchgear,
Earth rods, Stay Rods, Pole Make Off, Guy grip, stay wire, Crossarm, clamp, bolts, Line hardware
And so on. Our member companies are required to have a long term proven track record of meeting contract
Obligations, superior quality, current technology and state-of-the-art manufacturing facilities.
Over a period of 10 years, our business has extended to South America, Middle East, Southeast
Asia, Africa, and other regions, and we had our sale agent and 4S maintenance company in some countries. To achieve the strategic objective of development, we are seeking for partners
For our sale agent and maintenance company in all the worldwide.
