PVC Jacket and Copper Conductor Material Coaxial Cables

Name: PVC Jacket and Copper Conductor Material Coaxial Cables
Brand: all-electronics-online.com
SKU: 733569622
Availability: InStock
Rating: 4.6 (133 reviews)

Price:	US $ 0.1-30/Meter
Min Order:	100/Meter
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Executive Standard
International: IEC 60502-2, IEC 60228 IEC 60840;IEC62067
Chinese: GB/T 12706.2-2008
Other standards such as BS,DIN and ICEA upon request

Applications
The product is suitable for use in power transmission and distribution
lines or fixed installation with rated power frequency voltage up to and
including 0.6/1kv.

Operation Characteristics for PVC Jacket and Copper Conductor Material Coaxial Cables
1) Rated power-frepuency voltage U0/U: 0.6/1kv (Um=1.2KV).
2) Max. admissible operating temperature of the conductor:90ºC.
3) Max. short-circurt temperature of conductor shall not exceed 250ºC.
(5s maximum duration)
4) The ambient temperature under installation should not below 0ºC.
5) The bending radius of a single-core cable should not less than 20
times of the cable diameter.
The bending radius of a three-core cable should not less than 15 times
of the cable diameter.

Technical Parameters for PVC Jacket and Copper Conductor Material Coaxial Cables

Rated Voltage:	0.6/1KV
Core Number:	Single Core Two Core Three Core Four Core Five Core
Available Dimensions:	25mm2, 35mm2, 50mm2, 70mm2, 95mm2, 120mm2, 150mm2, 185mm2, 240mm2, 300mm2, 400mm2, 500mm2, 630mm2.
Codes Available:	N2XSY, N2XSEY, NA2XSY, NA2XSEY, N2XSRY, NA2XSRY, N2XSEBY, N2XSEYBY, NA2XSEBY, N2XSERY, NA2XSERY, N2XSEYRGbY, NA2XSEYRGbY, N2XS(F)2Y, NA 2XS(F)2Y, N2XS(FL)2Y, N2XSH, N2XSYRY
Codes Available:	YJV, YJLV, YJSV, YJLSV, YJV72, YJLV72, YJSV72, YJLSV72, YJV22, YJLV22, YJSV22, YJLSV22, YJV32, YJLV32, YJSV32, YJLSV32
Application:	For power networks, underground, outdoors and in cable ducting. It is recommended that the installation instructions indicated by the Local Electric Code, or any equivalent, be followed, so that the safeguarding of persons and the integrity of the product will not be affected during installation.
Construction:
Conductor:	Stranded round compacted copper or aluminum conductor (Cu / Al ), copper wire annealed.
Conductor Screen:	Semi-conducting material
Insulation:	XLPE (Cross-Linked Polyethylene)
Insulation Screen:	Semi-conducting material
Metallic Screen:	Copper tape screen or copper wire screen (CTS / CWS )
Filler:	PP rope
Separator:	Binding tape
Bedding:	PVC (Polyvinyl Chloride)
Armouring:	Single Core: Aluminium Wire Armoured (AWA) Multi-core: Steel Wire Armoured (SWA) or Steel Tape Armoured (STA)
Sheath:	PVC (Polyvinyl Chloride), flame retardant PVC, PE, LSOH, HFFR
Colour:	Red or Black
Temperature Rating:	0°C to 90°C
Minimum Bending Radius:	Single Core: 15 x overall diameter Three Core: 12 x overall diameter (Single Core 12 x overall diameter and 3 core 10 x overall diameter where bands are positioned adjacent to joint or terminations provided that the bending is carefully controlled by the use of a former)

Production Range for PVC Jacket and Copper Conductor Material Coaxial Cables

Type	Description	Number of cores	Nominal cross section of conductor (mm2)
			3.6/6kV	6/10kV 6.35/11kV	8.7/15kV	12/20kV 12.7/22kV	18/30kV 19/33kV 25/36kV
YJV	CU/XLPE/PVC electrical cable	1, 3	10~1000	16~1000	25~1000	35~1000	50~1000
YJLV	AL/XLPE/PVC electrical cable
YJSV	CU/XLPE/CWS/PVC electrical cable	1, 3	10~1000	16~1000	25~1000	35~1000	50~1000
YJLSV	AL/XLPE/CWS/PVC electrical cable
YJY	CU/XLPE/PE electrical cable	1, 3	10~1000	16~1000	25~1000	35~1000	50~1000
YJLY	AL/XLPE/PE electrical cable
Z-YJV	CU/XLPE Flame-retardant electrical cable	1, 3	10~1000	16~1000	25~1000	35~1000	50~1000
Z-YJLV	AL/XLPE Flame-retardant electrical cable
WDZ-YJY	CU/XLPE/LSHF(or LSZH) Flame-retardant electrical cable	1, 3	10~1000	16~1000	25~1000	35~1000	50~1000
WDZ-YJLY	AL/XLPE/LSHF (or LSZH) Flame-retardant electrical cable
N-YJV	CU/XLPE Fire-resistant electrical cable	1, 3	10~1000	16~1000	25~1000	35~1000	50~1000

Quality Assruance for Production Range for PVC Jacket and Copper Conductor Material Coaxial Cables

Prod Model:	Coaxial Cables
Product Name:	Coaxial Cables
Rated Voltage:	0.6/1 Kv
Conductor:	Copper
Insulation:	XLPE / PVC
Sheath:	PVC
Core Number:	1 2 3 4 5
Color Color:	Red , Yellow , Blue ,Green or as Your Requirement
Origine:	Shandong , China
Packaging:	Wooden Drum
Shipping:	3-10 Working Days
Application:	Power Station
Voltage:	Low and Medium Voltage Cable
Current:	DC & AC
Insulation Material:	XLPE
Certification:	VDE
Model:	XLPE Power Cable
Brand:	Chan Qing Teng

1) About Luxing Cable Factory:

-Shandong New Luxing Cable Co., Ltd established in the year of 1999.

-The headquarter is located in Jinan City, the capital of Shandong province, China.

-Registered capital of USD16.5 million, Legal representative Wang Xiuzhen.

-Luxing Cable Factory is located in Linyi Economic Development ZoneCovering an area of more than 60 acres.

-Shandong New Luxing Cable Co., Ltd has more than 150 employees, which college degree more than 50 people.

2)Why Choose Luxing Cable Factory?

-Luxing cable, the designated supplier of China's national grid construction.

-We provid high-quality cables for our clients for more than 18 years.

-The professional, safe and reliable of Luxing factory gained great trust and praise from our customers.

-Serve you any time.

3)The Product of Luxing Cable Factory

-300/500V 450/750V electrical wire

-600/1000V PVC insulated cable

-600/1000V XLPE insulated cable

-1.8/3KV to 26/35KV power cable

-Armored underground cable

-Control cable and instrumentation cables

-ABC cable

-AAC conductor

-AAAC conductor

-ACSR conductor

-OPGW

-Rubber cable

4)Product application

-Used for open air installation, for direct burrial underground, in water, in cable ducts, power stations, for industry and distribution boards and so on.

-Power transmission and distribution project bids we can work, cable retail and wholesale, regional agent we can cooperate.

5)Production Market

-Supply power cables & electrical wire to

South America(Brazil...),

East Asia(Korea...),

Africa(Uganda, South Africa, Zimbabwe...),

Southeast Asia(Myanmar, Thailand, Indonesia, Philippines, Malaysia, Cambodia...),

Europe(Czech Republic...) to global market.

-Had fixed partnership with SGCC&STATE GRID CORPORATION OF China (China largest power enterprise) and many other our country State-owned big enterprise.

6)Our service

-We guarantee that we will comply with the requirements of warranty period specified in the contract, that the Goods supplied under the purchase order For Procurement of self-carrying distribution network's cable and wire.

-We will be manufactured under this specification and that the Goods will be new, unused, of the most recent or current models. Once we are selected, we will supply the Goods strictly according to the requirements of the Contract.

-The warranty shall remain valid for twelve (12) months after the Goods, or any portion thereof as the case maybe, have been delivered to and accepted at the final destination indicated in the SCC, or for eighteen (18) months after the date of shipment from the port or place of loading in the country of origin, whichever period concludes earlier.

-During the warranty period purchaser may proclaim directly to the manufacturer in the written form or by the agent if there is any problem in Goods quality. The manufacturer will do the repair or replacement in reasonable time, and will bear all the expenses relating to this.
