Screw on RG6 F Type Satellite TV Antenna Connector

Product Description:
Screw on RG6 F type Satellite TV Antenna Connector:
Type F coaxial connector is the typical one used for 75Ω cable assignment system, especially for CATV, broadcast television network, closed-circuit television, utensil of branch, utensil of distributor. It can be used for impedance mating requirement occasion also can be used for no mating impedance occasion. Its characteristic is screw coupling, insert and close conveniently, stable performance, reasonable price.

FL10 product is M10X0.75 thread of metric; Type F is 3/8-32UNEF thread of English system. Type F connectors are interchangeable with the same-type connector of abroad.

Screw on RG6 F type Satellite TV Antenna Connector can be compressed to coaxial cable in which their unique dual compression ring technology provides excellent protection against moisture migration and offers superior holding strength for maximum longevity. The F connector is used for F type terminations for many coaxial applications including coaxial jumper cables used for antenna, cable, and satellite TV installations.





Temperature Range	-40~+60ºC
Vibration	100m/S²(10~500Hz)10g
Impedance	75Ω
Frequency Range	DC~1 GHz
Working Voltage	170V r.m.s  at sea level
Withstand Voltage	500V r.m.s  at sea level
Contact Resistant
Center Contact	≤10mΩ
Outer Contact	≤5mΩ
Insulation Resistance	≥1000MΩ
Center Conductor Retention Force	≥0.2N
Voltage Standing Wave Radio
Straight	≤1.20
Right Angle	≤1.30
Durability(Mating)	≥500(cycles)
