Single Phase Capacitor Run Motors

Name: Single Phase Capacitor Run Motors
Brand: all-electronics-online.com
SKU: 709500072
Availability: InStock
Rating: 4.8 (52 reviews)

Price:	US $ 23-55.2/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Product Description
ML series aluminum housing single-phase dual-capacitor asynchronous motors, with latest design in entirety, are made of selected quality materials andconforming to the IEC standard. ML motors have good performance, safety and reliable operation, nice appearance and can be maintained very conveniently, while with low noises, little vibration and at the same time of lightweight and simple construction. The compositive performance is good, and the multiple of starting torque is 1.8~2.5.

Technical Data

Type		Output	Voltage	At full load
		W	V	Speed	Current	Efficiency η%	Power factor
		W	V	r/min	A	%	CosΦ
DO₂	4512	10	220	2800	0.2	28	0.8
DO₂	4522	16	220	2800	0.26	35	0.85
DO₂	5012	25	220	2800	0.33	40	0.9
DO₂	5022	40	220	2800	0.42	42	0.9
DO₂	5612	60	220	2800	0.57	53	0.9
DO₂	5622	90	220	2800	0.81	56	0.95
DO₂	6312	120	220	2800	0.91	63	0.95
DO₂	6322	180	220	2800	1.29	67	0.95
DO₂	7112	250	220	2800	1.73	69	0.8
DO₂	4514	6	220	1400	0.2	17	0.8
DO₂	4524	10	220	1400	0.26	24	0.8
DO₂	5014	16	220	1400	0.28	33	0.82
DO₂	5024	25	220	1400	0.36	38	0.82
DO₂	5614	40	220	1400	0.49	45	0.85
DO₂	5624	60	220	1400	0.64	50	0.85
DO₂	6314	90	220	1400	0.94	51	0.85
DO₂	6324	120	220	1400	1.17	55	0.85
DO₂	7114	180	220	1400	1.58	59	0.88
DO₂	7124	250	220	1400	2.04	62	0.9

Package

Frame NO. 80--132 :Package by carton box and then packed by wooden box

For further informations,pls visit our web page without hesitate!

Contact Information:

Evan Zhou

Tel: 0574 55339278

Mob:0086+15158307112

www.hongmamotor.net

Prod Model:	YY/DO2
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Frame Size:	56-90
Rated Power:	0.06-2.2kw
Rated Voltage:	220V, 380V
Frequency:	50Hz, 60Hz
Protection Class:	IP44, IP54, IP55
Insulation Class:	B\F\H
Mounting Type:	B3, B5, B14, B35multi and Pad Mounting
Ambient Temperature:	-20~+40 °c
Altitude:	≤1000m
Efficiency Class:	Ie1
Application:	Industrial
Operating Speed:	Constant Speed
Number Of Stator:	Single-Phase
Rotor Structure:	Squirrel-Cage
Casing Protection:	Closed Type
Starting Mode:	y-δ Starting
Species:	Single Phase
Number Of Poles:	2, 4, 6
Certification:	Ce
Brand:	Hongma
