Steel Tape Armoured Sm Fiber Optical Cable

Steel Tape Armoured Sm Fiber Optical Cable
Price: US $ 0.10/Meter
Trade Terms: FOB,CFR,CIF
Min Order: 2KM
Pay Type: L/C,T/T,Paypal,Money Gram,Western Union
Prod Model: GYTS
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Fiber Cable: G652D.
Central Stength: FRP
Outer Jacket: PE Material
Application: Communication
Type: Single-mode Fiber
Connection Structure: ST
Certification: VDE
Brand: Surelink
Sheath Material: HDPE

Product Description

GYTS
1.Low dispersion and attenuation.

  • 2.Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental characteristics.
  •
  • 3. Steel tape armoured. PE sheath makes cable have nice moisture resistance performance.
  •
  • 4.Small cable diameter, light cable weight, easily to install.
  •
  • Main Technical Parameters
    Fiber
    number
    Cable diameter (mm)Cable net weight
    (Kg/km)
    Min. bending radius
    (mm)
    Min. tensile strength
    (N)
    Min. crush pressure
    (N/100mm)
    Static stateDynamic stateShort termLong termShort term

    Long

    term
    30 and below9.810710020015006001000300
    32~3610.412711022015006001000300
    38~6011.113812024015006001000300
    62~7211.917112024016006001000300
    74~8412.718413026017006001000300
    86~9613.419914028019006001000300
    98~10814.221915030020006001000300
    110~12015.024015030022006001000300
    122~13215.826016032024006001000300
    134~14416.527917034026006001000300
    Operating temperature-40~+60ºC
    *The structures in the list are all typical, the cable structure also can be design according customer's requirement.
