SUS Paddle Type Flow Switch for Non-Aggressive Fluid

Name: SUS Paddle Type Flow Switch for Non-Aggressive Fluid
Brand: all-electronics-online.com
SKU: 781894725
Availability: InStock
Rating: 4.8 (128 reviews)

Price:	US $ 1-11/Piece
Trade Terms:	FOB,CFR,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	FS-M-PDS01 series
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Medium:	Water, Non-Aggressive Fluid
Housing Material:	SUS
Max.Fluid Pressure:	1.5MPa
Contact Form:	Spst No
Protection Grade:	IP65

Product Description

Paddle Type Flow Switch(FS-M-PDS01 series)
Principle
Flow switch is the presence or absence of flow through the output switch control signal
to the water sensor switch, the main switch signal. Divided into specific types normally
open and normally closed type, in the main water control work flow monitoring role to
play. Water flow switch and relay use with the usual components of the water control
system, easy to use, no power is the flow switch on.

Model	FS-M-PDS01-GD	FS-M-PDS01-GE	FS-M-PDS01-GF	FS-M-PDS01-GG	FS-M-PDS01-GH	FS-M-PDS01-GI
Medium	Water and non-aggressive fluid
Housing material	SUS
Long time working temperature	≤80ºC
Max.fluid temperature	≤100ºC
Start-up flow rate	5L/min	7L/min	8L/min	10L/min	12L/min	15L/min
Max.fluid rate	15L/min	20L/min	50L/min	100L/min	120L/min	200L/min
Connection	G1/2''	G3/4''	G1''	G1.25''	G1.5''	G2''
Operate pressure	≤1.0Mpa
Max.fluid pressure	1.5Mpa
Electrical rate	0.5A/100VDC,10W	1A/250VAC,70W
Contact form	SPST NO
Protection grade	IP65

Bingo Industrial and Trading Company started to run businiess since 2006, which is located in Wenzhou Yueqing ---- The world-famous city for low-voltage electric apparatus.

We owns followed two subsidiary corporations:

Bingo sensor Technology Co., Ltd. ----- concentrates on pressure, level and flow control product.

Yueqing tongfa electronic Co., Ltd. ----- is engaged in electronic&electrical product, security product.

After several years development, Bingo now becomes a professional supplier for

* Pressure, level and flow control product applied to:

Water supply system

HVAC

Household appliances (refrigerator, Furnace, heater, dish-washing machine,

Water dispenser, food waste disposer and so on)

Steam control system

Vehicle

Oil transporting system

Medical equipment

* Security product

Warning light

Roadway safety

Mining safety

Alarm sire

* Electronic&Electrical product

Tact switch

Micro switch

Toggle switch

Foot switch

Earphone jacket

Industrial plug&socket

With many years' business accumulation and good cooperation with more than 150 companies, we are capable to offer our clients products with the competitive prices, satisfied quality and excellent services. Part of our products own CE, UL, TUV certificate.

At present, Bingo Industrial and Trading Company has 50-60 employees. We have set up business relationships with customers from more than 50 countries and regions. Through running business honestly, we earned the reputation from both local government and oversea clients.

We strongly insist on the principle of "quick response, the best service, satisfactory quality, and competitive price", and sincerely hope that every customer around the world would have the feeling of "Bingo" after the first business cooperation with us.

Looking forward to a win-win relationship with you!
