Tg180 HDI Blind Buried BGA Control Impedance PCB

Name: Tg180 HDI Blind Buried BGA Control Impedance PCB
Brand: all-electronics-online.com
SKU: 731647102
Availability: InStock
Rating: 4.7 (51 reviews)

Price:	US $ 10/Piece
Min Order:	1/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Product Description
TG180 HDI Rogers4003C control impedance

1. PCB, pcba, pcb design
2. UL, ROHS
3. Fast delivery with quality assured
4. ISO9001 certificate
5. Smt Pick And Place Pcb Assembly

Needed:
1. PCB gerber file.
2. BOM LIST FOR PCB ASSEMBLY.
3. Send us your sample pcb board or PCBA.

One-stop pcb assemblies service, We can offer 1 to 12 Layer PCB fabrication, PCB design, PCB layout, PCB manufacturing, PCB Assemblies, components sourcing, PCBA Function Test, design solution

Rigid PCB Capability
No.	Item		Technical data
1	Layer Count		1-30Layers
2	HDI Type		1+N+1, 2+N+2
3	Material		CEM3, FR-4, Halogen Free, Aluminum-based, Teflon,Rogers, Getek, Nelco, PTFE, Polyimide etc
4	Board thickness		0.2~5.0mm
5	Board Size	Max	600*1000mm (24"x40")
		Min	30x50mm
6	Copper Thickness	Outer layer	1oz~6oz
		Inner layer	Hoz~5oz
7	Min. Line Width/Space		4/4mil(0.1/0.1mm)
8	Finished Hole size	Mechanical	0.20~6.30mm
		Laser	5mil, 6mil
9	Blind/buried via(Mechanical)		0.2mm (min)
10	Aspect Ratio		10:1
11	Hole Dia.Tolerance	PTH	±0.075mm(3mil)
		NPTH	±0.05mm (2mil)
12	Hole Position Tolerance		±0.05mm (2mil)
13	Bow & Twist		≤0.75%
14	Peel strength		1.4N/mm
15	Thermal stress		288 degrees centigrade & 20 Sec
16	Test Voltage		50-300V
17	Soldermask color		Green, Red, Blue, Black, White
18			White, Black, Yellow
19			4mil(0.1mm)
20			0.05mm
21			±0.1
22	Outline Tolerance		±0.10mm (4mil)
23	Surface Finish		HASL, Lead free HASL, Immersion Gold/Tin/Silver, OSP, Flash Gold, Gold fingers, Plating Hard Gold, Carbon lnk, Peelable mask

Prod Model:	FD-TG180
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Fiberglass Epoxy
Flame Retardant Properties:	HB

Found PCB, established in 2005, Shenzhen Found Printed Circuit Board Co., Ltd. is part of Found group. Found PCB dedicated to provide one-stop service, to meet highest technology, quality and quick turn over challenges with lowest cost.

Shenzhen Found Circuit Board Co., Ltd supply all kinds of PCBs more than 10 years. Products including Rigid PCB (1-20 layers), flex PCB(1-4 layer), metal core PCB, Rigid-Flex PCB, especially in the metal core PCB, they use widly in the LED lighting.

A lot of comepays from Europe and North American buy from Found, cause we are the source, we can offer very good price, we think we can save a lot of your purchasing cost.

We also offer PCB solution. Such as Rigid-flex PCB, a lot of factories in China can not made this kind of the rigid-flex PCB. But Found is good at this...

With several year's rapid development, the production capability of our factory reachs 25, 000 square meters with over 500 employees and 180, 000 sq. M production area. Found PCB has been certified by International Quality System IS09001, ISO14001, TS16949 and UL (E361831).

We welcome the every opportunity to working for you. We have the good name in the PCB market.
