Z-Wave Remote Control Vibration and Shock Sensor (ZW105)

Name: Z-Wave Remote Control Vibration and Shock Sensor (ZW105)
Brand: all-electronics-online.com
SKU: 819619525
Availability: InStock
Rating: 4.8 (35 reviews)

Price:	US $ 19-33/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Introduction
Z-wave Remote Control Vibration and shock Sensor (ZW105)

Technical data Installation

Introduction

This device is an accessory of the Z-Wave system and enable detection of opened or knocked access your casement window /door in your home. ZW105 is a wireless, battery powered sensor, its two parts the sensor's body and a buzzer connected.

Technical data

Battery Operation	AAA * 3pcs (battery life 1 year)
Range	Min 30m line of sight
Operating temp	0~40 ºC
Working Voltage	4.5V
Dimensions	784216mm
Frequency	868.4MHz/865.2MHz/869.2MHz/908.4MHz/921.4MHz

Installation

1. First, add ZW105 to ZE200 controller or others, it must be in range of the controller, because the procedure of add to the ZE200 requires direct communication with the controller.
2. Set controller to "Add" mode, quickly pressing learn switch three times (the button is also the anti-packing switch).

3. After correct "Add" it to ZE200 controller it will be signaled by ZE200.
4. For "Remove" from a network: set up the Z-wave interface controller into "Remove" mode, and following its instruction to delete the ZW105 from your controller. Press the learn switch of ZW105 for 1 second at least &release to be excluded.
5.Use double EVA or screws to fix ZW105 on the Door/Window two sides, pls. be note correction position of the sensor and the magnet (dot-to-dot).
6.Re-setting ZW105: Remove the battery, touch the senor's body with magnet,
re-install battery, trigger ZW105 one time, and reset will be confirmed by LED blink.

Shipping &Packing

Prod Model:	ZW105
Battery Operation:	1.5V AAA Size *3PCS
For:	Ceramic Pressure Transmitter
Range:	Min 30m Line of Sight
Sensing Type:	White
Frequency:	868.42MHz/865.2MHz/869.0MHz/908.4MHz/921.4MHz
Production Process:	Injection
Wiring Type:	Wireless
Operating Temp:	0~40 Degrees
Contact:	Contactless
Main Part Dimensions(LWH):	784216mm
Certification:	RoHS, SGS, Ce
