1.2mm Thick 0.047" Electronics PCB Board Non-Conductive Via Fill
| Price: |
US $ 1.2/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-569-V5.69 |
| Aluminum Core: |
1W/Mk Dielectric Material |
| Thermal Resistance(°c/W): |
<=0.45 |
| Breakdown Voltage(VDC): |
4000 |
| Final Foil External: |
1 Oz |
| Final Height Of PCB: |
1.6mm |
| Surface Finish: |
Electroless Nickel Over Immersion Gold (Enig) |
| Solder Mask Color: |
White, Psr400 Wt02 |
| Colour Of Component Legend: |
No Silkscreen Required |
| Contour/Cutting: |
Aluminum Frame Conbined with Aluminum PCB |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Material: |
Aluminum |
| Dielectric: |
Aluminum 5052 |
Product Description
Company ProfileBicheng Enterprise Limited serves global clients from Shenzhen, China since 2003.
Variety of PCB technology to meet the market demands
HDI board
Heavy copper board
Hybrid material board
Blind via board
High frequency board
Metal core board
Immersion gold board
Multilayer board
Backplane board
Gold finger board
Aluminum PCB
High Frequency PCB
Flex PCB
PCB Circuit Board
ENIG
ENIG stands for Electroless nickel immersion gold which is a type of surface plating used for
circuit boards. It consists of an electroless nickel plating covered with a thin layer of immersion
gold. Normally, the thickness of nickel is 120µ" - 200µ" (3µm to 5µm ) and gold 1-5µ" (0.025µm
-0.127µm).
ENIG has several advantages than HASL, including
a) Excellent surface planarity, particularly helpful for PCBs with BGA packages or even CSP
mounted components to reduce failure rate during assembly and soldering.
b) Good oxidation resistance and good heat dissipation.
c) Long storage time (It can be stored for more than 1 year in vacuum bag)
d) High solderability, no stressing of circuit boards and less contamination of PCB surface.
e) SMT process is resistant to reflow soldering, resistant to rework.
Performance parameter of MCPCB substrate (The parameter will continue to be improved
without notice)| Test item | Unit | Aluminum base | Copper base | Iron base | Test method |
| Actual vale | Actual vale | Actual vale |
| Peel strength | N/mm | 2.2 | 2 | 2.3 | 4010 of
GJB1651 |
Surface
resistance | MΩ | 1 x (10^6) | 1 x (10^6) | 1 x (10^6) | 5020 of
GJB1651 |
Volume
resistance | MΩ.m | 3.2 x (10^7) | 3.2 x (10^7) | 3.2 x (10^7) | 5020 of
GJB1651 |
Breakdown
voltage | KV/min | ≥2.0 (Breakdown
voltage is
adjustable
according to
customers'
demend) | ≥1.0 (Breakdown
voltage is
adjustable
according to
customers'
demend) | ≥1.0 (Breakdown
voltage is adjustable
according to
customers'
demend) | 5040 of
GJB1651 |
| Solder dipping | ºC/min | 260ºC, 3 minutes,
no bubble and
delamination | 260ºC,
3 minutes,
no bubble
and
delamination | 260ºC,
3 minutes,
no bubble
and
delamination | 4010 of
GJB1651 |
| Flammability | - | FV-0 | FV-0 | FV-0 | 17 of GB/
T4722 |
Thermal
resistance | ºC/W | 0.25-1.2 | 0.25-1.2 | 0.25-1.2 | TO-220 |
Dielectric
constant | - | 3 | 3 | 3 | (40ºC,93%,
96h) |
Thermal
conductivity
of Dielectric | W/M.K | 0.8-8 | 0.8-350 | 0.8-3 | ASTM
5470-D |
Working
temperature | ºC | ≤120 | ≤120 | ≤120 | (40ºC,93%,
1Y) |
Thermal
conductivity
of metal base | W/M.K | ≥200 | ≥350 | ≥45 | ASTM |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
More >
