0.1 Class Current Transformer DC Immune Small Current Transformer Price

Prod Model:	DCT-603
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	Black
Product Mount:	PCB Mount
Model Type:	Current Voltage Transformer
Frequency:	50/60Hz
Accuracy:	0.1 Class Current Transformer
Application:	Instrument
Type:	Current Transformer
Phase:	Single

Product Description

Product description:

- Accurate DC measurement; - Suitable for a wide range of current(from 1.5 to 100A); - Linear output current, high precision; - Compact, delicate appearance; - Encapsulated with epoxy resin to ensure strong insulation ability. DC Tolerance - In normal condition,the power net is sinusoidal AC at loop, positive nd negative waves are symmetry. But in some special Conditions, the circuit have DC, then positive and negative waves will not be symmetry. Common current transformer would be saturation under this condition, and the meter used this CT have large error, even can not work, so just DC lmmunity CT can solve this problems. - As following figure to test the DC error, 0.1 accuracy CT will be controlled within ±3.0%,0.2 accuracy class CT will be controlled within ±6.0%.

Model	Specifications	Rated Pr current	Max Current	Rated Sec Current	DC immune	Load Resistance	Accuracy Class
DCT-603	5(30)A/2mA	5A	30A	2mA	≥22A	25Ω	0.1/0.2
	10(40)A/ 4mA	10A	40A	4mA	≥28.5A	20Ω	0.1/0.2
	10(60) A/ 4mA	10A	60A	4mA	≥43A	12.5Ω	0.1/0.2

Specifications
DC Immune Current Transformer
1. Small size,
2. high accuracy,
3.good consistency,
4. for current and power measurement
DC Immune Current Transformer
1. Small size,
2. high accuracy,
3.good consistency,
4. for current and power measurement

DC Immune Current Transformer

Features:
1. Meet the standard of IEC62053 and ANSI12.20
2. High linearity with DC immunity characteristics
3. Steady phase shift
4. Perfect insulation and excellent immunity of humidity ans shock
5. Various choices for different configurations
6. Meet ROHS requirements


Appliance to all kinds of high precise instrument,like single-phase or three-phase electronic type electric
DC immune High Precision Current Transformer Main characteristics
1. Adopt high magnetic permeability magnetic core, with high precision and good linearity and can resist DC component.
2.The range of applicable electric current is wide(5A-400A)
3.Primary input and secondary output ensure flexible and diversified forms as well as easy installation.
4.With a complete range of specification, products can be made according customers special requirements

Application
Electronic energy meter ,Power meter
Accurate measuring meter for AC at the existing DC components


We can produce it according to customers' requirements.


Electronic energy meter, power transducer, precision power meter and other power and energy monitoring devices
Over current protection circuit of motor and other electrical appliances
