1 Core G657A2 Self-Supporting FTTH Drop Cable

Prod Model:	FTTH drop cable
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Messenger Material:	Steel
Jacket Material:	LSZH
Installation Style:	Indoor & Outdoor Aerial
Outer Sheath Color:	Black or White
Fiber Counts:	1 Core or 2 Cores
Application:	Probe
Certification:	Reach
Type:	Glass Fiber
Connection Structure:	Optical Fiber
Sheath Material:	PVC,LSZH

Product Description

1 Core  G657A2 Self-Supporting FTTH Drop Cable

FTTH Overview:

Fibre to the Home (FTTH) is a unique technology being deployed by BSNL for the first time in India. The fibre connectivity having unlimited bandwidth and state of the art technology provides fix access platform to deliver the high speed broadband from 256 Kbps to 100 Mbps, IPTV having different type of contents like HDTV and future coming 3D TV and range of voice telephony services. It provides a comprehensive solution for the IP leased line, internet, Closed User Group (CUG), MPLS-VPN, VoIP, video conferencing, video calls etc whatever the services available on the internet platform, bandwidth on demand can be delivered by this connectivity to the without changing the access fibre and home device. Customer will get a CPE called Home Optical Network Termination (HONT) consist of 4X100 Mpbs Ethernet ports and 2 normal telephone ports. Each 100 Mbps ports will provide broadband, IPTVs, IP Video call and leased line etc as required by the customers. Customer will get power back unit having full load backup of four hours and normal backup of three days. This power backup will be AC input and connecting to the HONT on 12V DC.


Fiber Counts	Cable Dimension(mm)	Cable Weight(kg)	Long Term Tensile(N)	Short Term Tensile(N)	Long Term Crush(N/100mm)	Short Term Crush(N/mm)	Dynamic Min. Bend Radius(mm)	Static Min. Bend Radius(mm)	Range of Temperature(C°)
1-2	5.0*2.0	17.7	300	600	1100	2200	20H	10H	-20~+60

Recommended laying methods:
Used in access networks or as access cable from outdoor to indoor in customer premises networks

Structure characters:
Good mechanical and environmental characteristics
Flame retardant characteristics meet the requirements of relevant standard
The mechanical characteristics meet the requirements of relevant standard
Soft, flexible, easy to lay and splice and with big capacity data transmission
Meets various requirements of market and clients
