10 Layer PCB Rogers RO4003 Circuit Board Fabrication Electronics
| Price: |
US $ 1.87/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-592-V5.92 |
| Board Thick: |
1.6mm |
| Out Layer Copper: |
35um (1 Oz) |
| Inner Iayer Cu Thicknes: |
35 Um (1 Oz) |
| Soldermask Color: |
White,Kuangshun,Kuangshun |
| Silkscreen Color: |
Black,Kuangshun,Kam-388bk/Ksm28 |
| Mininum Trace (Mil): |
3 Mil |
| Minimum Gap(Mil): |
8 Mil |
| Surface Finish: |
HASL Lead Free |
| RoHS Required: |
Yes |
| Function: |
100% Pass Electrical Test |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
