10kv Composite Pin Insulators 3kn

Name: 10kv Composite Pin Insulators 3kn
Brand: all-electronics-online.com
SKU: 741193005
Availability: InStock
Rating: 5 (138 reviews)

Price:	US $ 1-10/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	10KV Composite pin insulators 3KN
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application:	High-voltage
Material:	Composite Polymer
Structure:	Post Insulator
Type:	A Type Insulator
Size Of Bearing Capacity:	3kn
Certification:	IEC
Color:	Gray and Red
Brand:	V

Product Description

1 Place of origin: China
2 Type: Station post insulator
3 Material: Polymer
4 Application: High Voltage Lines
5 Feature:
Good hydrophobicity
6 Color: Red, light grey or as per customer's requirement.

Type				FP W-10/3T20
Rated bent	withstand	load(kN)		3
Structure	height	(mm)		260
Max.	diameter	of insulating	shed (mm)	146
Min.	Electric arc	distance	(mm)	184
Min nominal	creepage	distance	(mm)	460
Diameter	of end	thread (mm)		20
Rated	voltage	(kV)		10
Highest	voltage of	equipment	(kV)	12
1min power	frequency wet	withstand voltage	not less than (kV)	50
Full wave lightning	impulse withstand	voltage(peak value)	not less than (kV)	110

VICCIA Electrical Co., Ltd., a member of Fuzhou Light Industry Co., Ltd, is located in Sanming City of Fujian Province. We specialized in manufacturing and supplying multiple products, particularly in the field of electrical appliance, such as Fiberglass ladder and Aluminum ladder, high and low voltage product, power fittings and so on. Started with the business of international trading and sales agent of domestic supplier and overseas buyer, we now have skilled and experienced engineer team in design and manufacturing, as well as trained talents in business and management which enables us to respond effectively to the demands of market and our customers at all times.

The slogan of VICCIA is to provide the highest quality services to each customer, and to provide products to each customer with reasonable price and good quality. At the same time, we can develop and manufacture gratifying products in accordance with customers' certain requirements.

Put your trust in VICCIA, let us work together and achieve more.
