12 AWG PVC Insulated Single Core Wire Electrical Cable Wire

Name: 12 AWG PVC Insulated Single Core Wire Electrical Cable Wire
Brand: all-electronics-online.com
SKU: 733270512
Availability: InStock
Rating: 4.5 (141 reviews)

Price:	US $ 0.1-1/Meter
Min Order:	100/Meter
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	12 AWG PVC Insulated Single Core Wire
Product Name:	Low Voltage 450/750V PVC Solid Copper Wire Cable
Rated Voltage:	300/500V 450/750V
Conductor:	Copper / Aluminum
Insulation:	PVC / XLPE
Certificates:	ISO CCC Ce RoHS
Origine:	Shandong China
Color:	Red, Yellow, Blue, Green, Yellow/Green, Black etc
MOQ:	100 Meter
Packaging:	100 Meter Per Roll
Shipping:	by Sea, by Train, by Air
Type:	Insulated
Conductor Material:	Copper
Insulation Material:	PVC
Certification:	GB/T Standard
Conductor Type:	Solid / Stranded
Application:	Fixed Wire
Sheath Material:	Non
Range Of Application:	Lsoh / Flame -Retardant
Brand:	Chanong Qing Teng

Product Description

We are the factory.

We can provide competitive price and spot supply.

We offer door-to-door service.

We supply 12 AWG PVC Insulated Single Core Wire Electrical Cable Wire for famous enterprises
and bidding project.

Iterm Name : 12 AWG PVC Insulated Single Core Wire Electrical Cable Wire

1.BV electrical wiring for sale

2.Class 1 or 2 conductor

3.PVC insulation

4.1 core,0.5-630 sqmm

5.IEC,BS,VDE,UL,AS/NZS,GB

BV electrical wiring for sale are used for general purpose, as building wire for power, lighting and control wire to
electrical appliances, suitable for use in conduit and for fixed, protected installation

1.U0/U :300/500v 450/750v

2.Standard Applied: IEC 60227, GB/T5023, VDE0281, BS6004.

3.Max.working temperature:70°C, can be 90°C and 110°C as per requirement

4.Conductor :solid or standard pure annealed copper

5.Insulation:PVC /LSOH

6.Cores:1 core

7.Cross section area:0.50~630mm2

8.Sheath:Without sheayh

9.Color:black or as per requirement

10.Flame retardent or Fire resistance or Low smoke and halogen free or other property can be available

11.100 m per roll or as as per requirement

12.Certification:ISO9001, ISO14001,OHSMS18001,CCC,etc.

13.OEM can be available

BV Cable,flexible copper cable,BVR,BV,RV cable,BVR cable

insulated Power cable BV,BVR,RV . 1MM2,1.5MM2,2.5MM2,4MM2.....

Home installation cable

flexible copper cable PVC 1mm2, 2mm2 and 3mm2 (any color)

Conductor		Insulation		70°C(MΩKM)
Sectional area(mm2)	Constructiong (NO/mm)	Nom.Thick(MM)	Nom.Daim(MM)	70°C(MΩKM)
0.50	16/0.2		2.15	0.013
0.75	24/0.2	0.6	2.35	0.011
1.00	32/0.6		2.55	0.010

Conductor			Insulation		Max DC Resistance (Ω/Km. 20°)	Minimum insulation resistance (M Ω/Km. 70°C)	Compressive strength (KV.5MIN)
Nominal cross section (mm)	Structure (NO/MM)	Nom. Dia.(mm)	Nom. Thick.(mm)	Nom. Dia.(mm)	Max DC Resistance (Ω/Km. 20°)	Minimum insulation resistance (M Ω/Km. 70°C)	Compressive strength (KV.5MIN)
2.5	19/0.41	2.05	0.8	2.65	7.41	0.011	2.500
4	19/0.52	2.6	0.8	4.20	4.61	0.009	2.500
6	19/0.64	3.2	0.8	4.80	3.08	0.0084	2.500
10	49/0.52	4.38	1.0	6.38	1.83	0.0072	2.500

Workshop: We are factory.

Shandong New Luxing Cable Co.,Ltd. Our factory specialized in manufacturing kinds of cable products(power cable,
cable wire electrical, bare wire...) since 1999. Our company have Tengzhou,Dezhou and Wuxi city three production
bases and current employees more than 700. Our cables in good quality standard and have CE,ISO9000/14000,CCC,
IEC,BS,AWM/AWGstandard certifications. Our company had fixed partnership with SGCC&STATE GRID
CORPORATION OF CHINA(China largest power enterprise) and many other our country State-owned big enterprises.
And supply IEC/BS standard cable wire electrical & power cable to Africa( Uganda,South Africa,Zimbabwe...),
Southeast Aisa (Myanmar,Thailand,Indonesia,Philippines,Malaysia...), East Asia(Korea...), South America(Brazil...),
Europe(Czech repulic...) market.

Luxing Cable Factory Mainly Produce

300/500V 450/750V electrical wire	AAC conductor
600/1000V PVC insulated cable	AAAC conductor
600/1000V XLPE insulated cable	ACSR conductor
1.8/3KV to 26/35KV power cable	OPGW
Armored underground cable	ABC cable
Control cable and instrumentation cables	Rubber cable

Why choose us?

1. Advanced process equipment

2. Competitive price and high quality

3. Excellent after-sale service

4. Attractive design and various styles

5. Powerful technology R&D team

6. Strict quality assurance system and perfect testing means

7. Advanced process equipment

8. Delivery on time

9. Have a good reputation in the domestic and overseas.

Contact us

1) About Luxing Cable Factory:

-Shandong New Luxing Cable Co., Ltd established in the year of 1999.

-The headquarter is located in Jinan City, the capital of Shandong province, China.

-Registered capital of USD16.5 million, Legal representative Wang Xiuzhen.

-Luxing Cable Factory is located in Linyi Economic Development ZoneCovering an area of more than 60 acres.

-Shandong New Luxing Cable Co., Ltd has more than 150 employees, which college degree more than 50 people.

2)Why Choose Luxing Cable Factory?

-Luxing cable, the designated supplier of China's national grid construction.

-We provid high-quality cables for our clients for more than 18 years.

-The professional, safe and reliable of Luxing factory gained great trust and praise from our customers.

-Serve you any time.

3)The Product of Luxing Cable Factory

-300/500V 450/750V electrical wire

-600/1000V PVC insulated cable

-600/1000V XLPE insulated cable

-1.8/3KV to 26/35KV power cable

-Armored underground cable

-Control cable and instrumentation cables

-ABC cable

-AAC conductor

-AAAC conductor

-ACSR conductor

-OPGW

-Rubber cable

4)Product application

-Used for open air installation, for direct burrial underground, in water, in cable ducts, power stations, for industry and distribution boards and so on.

-Power transmission and distribution project bids we can work, cable retail and wholesale, regional agent we can cooperate.

5)Production Market

-Supply power cables & electrical wire to

South America(Brazil...),

East Asia(Korea...),

Africa(Uganda, South Africa, Zimbabwe...),

Southeast Asia(Myanmar, Thailand, Indonesia, Philippines, Malaysia, Cambodia...),

Europe(Czech Republic...) to global market.

-Had fixed partnership with SGCC&STATE GRID CORPORATION OF China (China largest power enterprise) and many other our country State-owned big enterprise.

6)Our service

-We guarantee that we will comply with the requirements of warranty period specified in the contract, that the Goods supplied under the purchase order For Procurement of self-carrying distribution network's cable and wire.

-We will be manufactured under this specification and that the Goods will be new, unused, of the most recent or current models. Once we are selected, we will supply the Goods strictly according to the requirements of the Contract.

-The warranty shall remain valid for twelve (12) months after the Goods, or any portion thereof as the case maybe, have been delivered to and accepted at the final destination indicated in the SCC, or for eighteen (18) months after the date of shipment from the port or place of loading in the country of origin, whichever period concludes earlier.

-During the warranty period purchaser may proclaim directly to the manufacturer in the written form or by the agent if there is any problem in Goods quality. The manufacturer will do the repair or replacement in reasonable time, and will bear all the expenses relating to this.
