126kv Composite Station Post Insulator

Name: 126kv Composite Station Post Insulator
Brand: all-electronics-online.com
SKU: 741192905
Availability: InStock
Rating: 4.3 (60 reviews)

Price:	US $ 2-15/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	126KV Composite Station post insulator
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application:	High-voltage
Material:	Composite Polymer
Structure:	Post Insulator
Type:	B Type Insulator
Size Of Bearing Capacity:	10kn
Certification:	IEC
Color:	Gray and Red

Product Description

1 Place of origin: Fujian China
2 Type: Station post insulator
3 Material: Polymer
4 Application: High Voltage Lines
5 Feature:
Good hydrophobicity
6 Color: Red, light grey or as per customer's requirement.

Type	Height	Min. Electric	Min nominal	Rated mechanical		Power frequency		Full wave lightning	Highest operating
	(mm)	arc distance	creepage	failing load		withstand voltage		impulse withstand	voltage of
		(mm)	distance					voltage(peak value)(kV)	equipment (kV)
			(mm)	Bend	Distortion	1min Wet	1min Dry
				(kN)	(kN)	(kV)	(kV)
FZS -126/10	1220	1060	3180	10	4	185	265	450	126

VICCIA Electrical Co., Ltd., a member of Fuzhou Light Industry Co., Ltd, is located in Sanming City of Fujian Province. We specialized in manufacturing and supplying multiple products, particularly in the field of electrical appliance, such as Fiberglass ladder and Aluminum ladder, high and low voltage product, power fittings and so on. Started with the business of international trading and sales agent of domestic supplier and overseas buyer, we now have skilled and experienced engineer team in design and manufacturing, as well as trained talents in business and management which enables us to respond effectively to the demands of market and our customers at all times.

The slogan of VICCIA is to provide the highest quality services to each customer, and to provide products to each customer with reasonable price and good quality. At the same time, we can develop and manufacture gratifying products in accordance with customers' certain requirements.

Put your trust in VICCIA, let us work together and achieve more.
