12V 48W Dimmable CV DC LED Driver ETL (UL) Approved

Name: 12V 48W Dimmable CV DC LED Driver ETL (UL) Approved
Brand: all-electronics-online.com
SKU: 839300375
Availability: InStock
Rating: 4.6 (137 reviews)

Price:	US $ 16-17/Piece
Min Order:	10/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	DR-48
Item Name:	ETL Dimmable 12V 50W LED Driver
IP Degree:	IP44
Output Voltage:	12V/24V Constant Voltage
Output Current:	4000/2500mA
Power Factor:	>0.95
Cover Material:	Plastic
Cover Color:	White
Application:	LED Strip Light, LED Rigid Bar,MR16 Spotlight
Suit For Dimmer:	Leading Edge or Trailing Edge
Dimming Range:	5%-100%
Output Type:	Single
Input Voltage:	110V
Connection Mode:	Parallel Switching Power Supply
Starting Mode:	Separate-excited Switching Power Supply
Voltage Regulating Mode:	Width Modulation Type
Power Supplying System:	Level 2 Power Distribution Equipment
Certification:	ETL
Warranty:	5years
Output Power:	50watt
Brand:	Sunred

Product Description

12v 48w dimmable CV DC Led driver ETL(UL) Approved
120VAC TO 12V 24V DC led transformer for led strip ,MR16 led spotlight
ETL UL listed ac to dc 12v 24v 12w 30w 50w 60w led driver available

12V/24V led driver, ETL/UL,Input voltage 90-130V for North America

One channel constant voltage triac dimmable led driver.Constant current or Constant Voltage.triac Dimmable/0-10V Dimmable/DALI Dimmable/Non-Dimmable

Constant Voltage
Input Voltage(V/AC):110V&230V
Input Power(W):50-60W
Output Voltage(V/DC):12/24
Output Current(mA):4000/2500
PF:>0.95
Efficiency((%):>82%
Dielectric Strength(V/AC):3000
Thermal Dissipation:Nature
Relative Humidity:5~95%
Isolation Voltage:In/Out 3000VAC
Vibration:5-55hZ/2G,30Minutes
Life time:50000H,AT tc max

Main Features
1.Advanced patent dimming technology
2.Suitable for leading edge or tailing edge dimmers
3.Short cicuirt and over current and over voltage protection
4.Recycle and no hazardous substance
5.Double isolation design for human safety
6.Conveniently connected terminals(screws)
7.Fireproof environmental protection cover.

Carton box packing:

44pcs/carton, gross weight:12kg, size: 38*27*27cm

Sells very well in North Ameria, Europ and Australia.
With 6years Sell experience to America only 1/5000 failure.
Welcome for your inquiries!

SUNRED LED Co., Limited!

We are LED driver manufacturer and LED car lighting trader located in Shenzhen, China

Which established in 2017.

Our main products are

0-10V/PWM dimmable drivers.

TRIAC dimmable LED driver,

DALI dimmable LED driver

IP67 Waterproof LED power supply

Low voltage LED transformer

LED car lighting

We have many good partners and suppliers, all of our products are with certificates,

CE EMC LVD TUV for Europ and SAA for Australia, For America market we have ETL UL certificates.

Also we can offer you good price, acceptable lead time and excellent after sale service.

Sunred LED, this young and flexible company will keep the innovation and honest in heart. To built a long good and mutual business relationship with you. Always fighting to prop the hope of green and lighten the future of the world.
