12V5a 13.5V1a AC/DC EPS Power Supply for Access Control

Name: 12V5a 13.5V1a AC/DC EPS Power Supply for Access Control
Brand: all-electronics-online.com
SKU: 731650062
Availability: InStock
Rating: 4.6 (88 reviews)

Price:	US $ 11-12/Piece
Min Order:	50/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	5310
Item No.:	5308 13.5/8A 5304 13.5V/4A 5310 13.5V10A
Input Frequency Range:	50/60Hz
Over Voltage:	115%~150%
Overload:	105%~150%
Cooling Methed:	Natural Cooling
Work Temperature:	-10ºC~60ºC
Phase:	Single Phase
Type:	Standby
Protection:	Over Voltage, Short Circuit, Over Current
Application:	Security System/LED Lighting/Industry
Brand:	Sanyi Power

Product Description

Rechargeable power supply with protection for battery
1.Features:
>International Universal AC input/ Full range
>Battery floating long-line, high charging efficiency, battery saturation can be up to 90%
>Stoped to prevent overcharging, effectively extending the battery life
>Mains / battery automatic switchover time is very short, without staff on duty
>Can directly start the UPS batteries to meet emergency needs of users
>Charging overvoltage and undervoltage protection
>Built-in EMI filter
>100% full load burn-in test
>High efficiency, long life and high reliability
>Can be customized according to user selection
2.Specification:

MODEL	5310-12		5310-24
	CH1	CH2	CH1	CH2
DC Voltage	13.5V	13.5V	27V	27V
Rated Current	10A	/	5A	/
Current Range	0~10A	/	0~5A	/
Charging Voltage	/	13.5V	/	27V
Charge Current	/	0~1A	/	0~1A
Rated Power	135W	/	135W	/
Ripple & Noise Max(Note2)	120mVp-p	/	120mVp-p	/
Voltage Adj. Range	±10%	/	±10%	/
Voltage Tolerance(Note 3)	±5%	/	±5%	/
Load Regulation(Note 4)	±0.5%	/	±0.5%	/
Voltage Tolerance(Note 5)	±1.0%	/	±1.0%	/
Setup,Rise Time	500ms,50ms/220Vac	(Full load)
Hold up time(Typ.)	50ms/220Vac	(Full load)

3.Model

4.Factory Profiles

5.Certificate

6.Contact
SHENZHEN SANYI TECHNOLOGY CO.,LTD
Web: www.szsanyi.com
Attn:rubychen
Phone+86 18688739138
Tel: +86 755 28986673
Add: Floor 4, Block 1,HongJiaTai Industrial Area, XinTun Village,AiLian Community, LongGang District,Shenzhen 518172,China

SHENZHEN SANYI TECHNOLOGY CO. Ltd established in 2004 is a high-tech company integrating R&D, manufacture, and marketing. We are specialized in a series of products including switch power supply, adapter, LED power supply, LED driver, outdoor waterproof adapter, surveillance power supply, EPS power supply, adjustable light LED driver, and so on. These products are widely used in security & protection system, LED lighting and display, industrial control, commercial equipment, data communication, solar power inverter, etc. Our factory covers over 5, 000 square meters and operate under TUV(GMC) guidelines. Monthly, it outputs more than 2, 000, 000 power supply units.

We are equipped with all kinds of production and testing facilities including the automated production lines, the switch power supply test system, the EMC testing system, RoHS testing instruments, environment testing chamber, high temperature aging room, etc. Every product has a full load rate of 100%, and the annual failure rate is less than 0.2%. With excellent quality and service, our products have been always popular and satisfactory around the world. The brand "AP Electric" affiliated to SANYI has become one of the most famous brand in Chinese power supply market.

We also apply the ERP enterprise resource management system to optimize our enterprise workflow. An energetic, intelligent, and creative R&D team keeps innovating and ensuring our lead in this industry. Till now, a considerable amounts of national patents have been achieved. Meanwhile, we adhere "AP electric, seeking increasing perfection" as our belief. Our company has been qualified by ISO 9001 certificate of quality system, and all of our products have been certificated by UL, TUV, CCC, CE, UL, CB, FCC and RoHS.
