140W 104mm AC Induction Gear Motor

Name: 140W 104mm AC Induction Gear Motor
Brand: all-electronics-online.com
SKU: 775238655
Availability: InStock
Rating: 5 (145 reviews)

Price:	US $ 47.98-88.98/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	GS6IK140GU
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output Power:	140W
Voltage:	100/110/120/220/230V
Frequency:	50/60Hz
Rated Torque:	1080mn.M
Rated Speed:	1250rpm
Phase:	1pH/3pH
Gearbox:	Can Be Provided
Number Of Stator:	Single-Phase
Function:	Control
Certification:	UL CE
Brand:	Greensky

Product Description

60mm~104mm, 6W~180W AC Induction Motor

Introduction

Generally, Micro Induction Motor refers to the motor rotated by the induction. Induction Motor relies on capacitor and electromagnetism when starting and rotating. Though its starting torque is not very high, it has a simple structure, high efficiency and can rotate continue.

Specifications

1. Dimensions of device: 104mm
2. Rated Power: 140W
3. Voltage: 100/120/220/230V
4. CCC, CE, UL, CU
5. Can be customized

SPECS/CONTINUOUS RATING

Model		Output power	Voltage	Frequency	Current	Starting Torque	Rated Torque	Rated Speed	Capacitor
Lead Wire Type	Terminal Box Type	W	V	Hz	A	mN.m	mN.m	r/min	μF
GS6IK140GU-AF	GS6IK140GU-AFT	140	1ph100	50	2.7	700	1080	1250	35
				60	3		870	1550
GS6IK140GU-EF	GS6IK140GU-EFT	140	1ph110	60	1.8	700	850	1600	25
			1ph120		1.95
GS6IK140GU-CF	GS6IK140GU-CFT	140	1ph220	50	1.05	850	1040	1350	10
			1ph230		1.15
GS6IK140GU-HF	GS6IK140GU-HFT	140	1ph220	60	1.05	750	850	1600
			1ph230		1.15
GS6IK140GU-SF	GS6IK140GU-SFT	140	3ph220	50	0.85	2700	1080	1250	-
				60	0.75	2200	870	1550

Allowance Torque Unit: Upside (N.m)/ Belowside (kgf.cm)

TYPE Motor/Gearhead	Gear Ratio		3	3.6	5	6	7.5	9	12.5	15	18	25	30	36	50	60	75	90	100	120	150	180	200
TYPE Motor/Gearhead	Speed r/min	50Hz	500	417	300	250	200	166	120	100	83	60	50	41	30	25	20	16	15	13	10	8.3	7.5
GS6IK140GU-AF GS6IK140GU-CF	6GUK	50Hz	2.6	3.1	4.4	5.2	6.6	7.9	9.9	11.8	14.2	17.8	21.4	25.7	36	40	40	40	40	40	40	40	40
GS6IK140GU-AF GS6IK140GU-CF			27	32	44.8	53	67.3	80.6	101	120	144	181	218	262	363	400	400	400	400	400	400	400	400
GS6IK140GU-SF			2.5	3	4.2	5.1	6.3	7.6	9.5	11.4	13.7	17.2	20.6	24.7	34	40	40	40	40	40	40	40	40
			26	31	42.8	52	63.2	77.5	96.6	116	139	175	210	252	349	400	400	400	400	400	400	400	400
			26	31	42.8	52	63.2	77.5	96.6	116	139	175	210	252	349	400	400	400	400	400	400	400	400

TYPE Motor/Gearhead	Gear Ratio		3	3.6	5	6	7.5	9	12.5	15	18	25	30	36	50	60	75	90	100	120	150	180	200
TYPE Motor/Gearhead	Speed r/min	60Hz	600	500	360	300	240	200	144	120	100	72	60	50	36	30	24	20	18	15	12	10	9
GS6IK140GU-AF GS6IK140GU-EF GS6IK140GU-HF	6GUK	60Hz	2.1	2.5	3.5	4.2	5.3	6.3	7.9	9.5	11.4	14.4	17.2	20.7	29	35	40	40	40	40	40	40	40
GS6IK140GU-AF GS6IK140GU-EF GS6IK140GU-HF			21	26	35.7	42.8	54	64.2	80.6	96.9	116	147	175	211	292	352	400	400	400	400	400	400	400
GS6IK140GU-SF			2.1	2.5	3.4	4.1	5.2	6.2	7.8	9.3	11.2	14.3	16.8	20.2	28	34	40	40	40	40	40	40	40
			21	26	34.6	41.8	53	63.2	79.5	94.8	114	146	171	206	285	343	400	400	400	400	400	400	400
			21	26	34.6	41.8	53	63.2	79.5	94.8	114	146	171	206	285	343	400	400	400	400	400	400	400
