150kw Single Cabinet Two Guns Output Integrated EV Charger

Name: 150kw Single Cabinet Two Guns Output Integrated EV Charger
Brand: all-electronics-online.com
SKU: 727781802
Availability: InStock
Rating: 4.6 (88 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	GPDC750V160-HV/GPDC750V80-HV
Power Factor:	≥0.99
Voltage Regulation:	≤±0.5%
Full Load Efficiency:	≥96%
Protection Class:	IP55
Mtbf:	>400, 000 Hours
Output Voltage:	200~750VDC
Operating Temperature:	-40~+65ºC
Acoustic Noise:	≤65dB
Weight:	215kg
Communication Port:	Can/RS485/WLAN/ Bluetooth
Output Type:	Multiple
Warranty:	2 Years
Certification:	ISO
Output Power:	150kw
Input Voltage:	260~530VAC
Brand:	Goldpower

Product Description

150KW Single Cabinet Two Guns Output Integrated EV Charger is HVDC fast chager.

Feature:
1. Compatible design for 15kW and 30kW module;
2. Single cabinet 150KW, two gun outputs;
3. Faultless thermal design, IP55 protection level.
4. Dynamic power distribution technology, Realized the best efficiency and reduce operation costs
5. Reliable performance from long-term operation experience.
6. Support State Grid and individual charging service operator.
7. With uplink communication port, to achieve unified background management of the charging pile group.

Application:
1. The charging equipment manufacturers of new energy vehicles, the operators of charging service.
2. Office building, shopping center, residential community, commercial property management providers, as well as the operator of Industrial Park.
3. Highway and social public parking lot operation manager
4. Various types of electric buses, cars, mini electric vehicles, logistics vehicles and other new energy vehicles operating companies
5. New energy vehicles after-sales service points, spare parts suppliers.

Specification:

Model	GPDC750V160-HV	GPDC750V80-HV
Power	120KW	60KW
Input voltage	260~530Vac	260~530Vac
Input frequency	45~65Hz	45~65Hz
Output voltage	200~750Vdc	200~750Vdc
Low voltage auxiliary power output	12V/24Vdc	12V/24Vdc
Power factor	≥0.99	≥0.99
Voltage regulation	≤±0.5%	≤±0.5%
Current regulation	≤±0.5%	≤±0.5%
THD	≤3%	≤3%
Full load efficiency	≥96%	≥96%
Current sharing	≤±5%	≤±5%
MTBF	>400,000 hours	>400,000 hours
Ripple(peak to peak)	≤±0.5%	≤±0.5%
Start-up time	Soft-staring 8s	Soft-staring 8s
Operating temperature	-40~+65ºC	-40~+65ºC
Audible Noise	≤65dB	≤65dB
Communication port	CAN/RS485/WLAN/ Bluetooth	CAN/RS485/WLAN/ Bluetooth
Protection class	IP55	IP55
lightning protection	20kA	20kA
Dimensions	750×1800×800mm 2 guns	700×1800×600mm2 guns
Weight	215kg	165kg
Protection	Input over/ under voltage, phase-lacking, output over voltage, short circuit, over temperature, failure isolation	Input over/ under voltage, phase-lacking, output over voltage, short circuit, over temperature, failure isolation
