1550nm Splitter CATV Optical Signal Monitoring System
| Price: |
US $ 4-6/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union,Money Gram |
| Prod Model: |
SSBC-12-15-01-E-09-10-LU |
| Ports: |
1X2 Ways |
| Wavelength: |
1550+/-40nm |
| Fiber Type: |
SMF-28e |
| Steel Tube: |
3/54mm |
| Loose Tube: |
0.9mm |
| Coupling Ratio: |
1:99 |
| Max. Power: |
30dBm |
| Application 1: |
Gpon |
| Application 2: |
Access Network |
| Application 3: |
FTTH |
| Type: |
CATV（Cable Television）Equipment |
| Function: |
Signal Transmission Equipment |
| Certification: |
RoHS |
| Condition: |
New |
Product Description
DescriptionThe Single Mode Broadband Fiber Coupler based on Two Parallel Fiber
fused bi-conical taper technology. It has single or multi window. The devices are designed and manufactured to meet Telcordia GR-1209-CORE requirements and RoHS compliant.Applications FeaturesTelecommunication system Low excess lossLine monitor system Low PDLAccess network High reliabilityOCT system AmplifierCATV Ordering InformationSSBC- - - - - - - -
| Ports | Wavelength | Coupling ratio | Fiber Type | Pigtail Dia. | Pigtail Length | Package | Connector Type |
| 12=1x2 | 82=820nm | 01=01/99 | H=Hi 780 | 02=0.25mm | 05=50cm | A1(2, 3,) | FU(A)=FC/UPC(APC) |
| 22=2x2 | 98=980nm | 02=02/98 | F=Flex 1060 | 09=0.9mm | 10=100cm | B1(2) | SU(A)=SC/UPC(APC) |
| / | … | … | E=SMF-28e | 2=2mm | … | C1 | … |
| | 13=1310nm | 40=40/60 | B=SMF-28e XB | 3=3mm | 20=200cm | D1 | LU(A)=LC/UPC(APC) |
| | 35=1310&1550nm | 00=50/50 | / | X=Customization |
Package and Mounting Dimension (mm)| Stainless Steel Tube (A) | Plastic Box (B) | Aluminum alloy Box (C) | Aluminum alloy Rack (D) |
| Outline | Outline | Outline | Mounting | Outline | Mounting | Outline |
| A1=Φ3x50 | A5=Φ5.5x34 | B1=90x20x9.5 | 50x12x2Φ3.2 | C1=85x18x8.4 | 44.5x13x2Φ3 | D1=129x29x160 1U LGX |
| A2=Φ3x54 | A6=Φ5.5x38 | B2=100x80x10 | 70x73.5x4Φ3.2 | C2=90x72x8 | 86x68x4Φ3 | D2=129x58x160 2U LGX |
| A3=Φ3x60 | A7=Φ5.5x50 | B3=120x80x18 | 80x74.5x4Φ3.2 | C3=110x95x7.5 | 99x84x4Φ3.5 | D3=485x43.5x230 1U 19' RACK |
| A4=Φ5x70 | A8=Φ5.5x64 | B4=141x115x18 | 100x106x4Φ3.2 | C4=110x95x15 | 99x84x4Φ3.5 | D4=485x87x230 2U 19' RACK |
| Item | φ0.25 Stainless | φ0.9 Stainless | φ2/3 Stainless | φ0.9(φ2,φ3) Plastic | φ0.9(φ2/φ3) Aluminum Alloy | LGX | 19' Rack |
| 1x2 | A1 | A2 | A4 | B1 | C1 | D1 | D3 |
| 2x2 | A1 | A3 | A4 | B1 | C1 | D1 | D3 |
SpecificationOperating
Wavelength(nm) | 820±40/980±40/
1310±40/1550±40 | 980&1550±40/
1310&1490&1550±40 | Parameter | Unit | Value |
Coupling
Ratio (%) | Insertion Loss (dB) | Fiber Type | / | Hi 780/ Flex 1060/
SMF-28e/ SMF-28e XB |
| Tap | Signal | Tap | Signal |
| 01/99 | 19.0-21.0 | ≤0.20 | 18.5-21.5 | ≤0.25 | PDL | dB | Typ.:<0.1 Max.:<0.15 |
| 03/97 | 14.6-16.2 | ≤0.30 | 14.5-16.5 | ≤0.30 | Directivity | dB | >55 |
| 05/95 | 12.4-13.8 | ≤0.35 | 12.0-14.5 | ≤0.45 | Return Loss | dB | >50 |
| 10/90 | 9.70---10.7 | ≤0.60 | 9.70-11.2 | ≤0.60 | Excess Loss | dB | Typ.:<0.1 Max.:<0.2 |
| 20/80 | 6.70---7.60 | ≤1.15 | 6.60---7.80 | ≤1.15 | Pigtail Dia. | mm | 0.25 /0.9 / 2 / 3 |
| 33/67 | 4.65---5.65 | ≤1.70 | 4.50---5.85 | ≤1.80 | Pigtail Length | cm | >100 |
| 40/60 | 3.95---4.30 | ≤2.50 | 3.70---4.70 | ≤2.70 | Operating Tem. | ºC | -10~ +70 |
| 50/50 | 2.85---3.30 | 2.80---3.40 | Storage Tem. | ºC | -40~ +85 |
