15V 12A LED Mini Switching Power Supply
| Price: |
US $ 4.17-6/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
| Prod Model: |
S-25 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| OEM, ODM: |
Accepted |
| Warranty Time: |
18 Months |
| Type: |
Single Output |
| Efficiency: |
88% |
| Output Type: |
Single |
| Warranty: |
2 Years |
| Output Power: |
1 - 50W |
| Input Voltage: |
Full Range |
| Connection Mode: |
Series Switching Power Supply |
| Starting Mode: |
Self-excited Switching Power Supply |
| Voltage Regulating Mode: |
Frequency Modulation Type |
| Power Supplying System: |
Level 1 Power Distribution Equipment |
| Certification: |
CE |
| Brand: |
Jyins |
Product Description
1. Our company is a professional manufacture and OEM.
CE and ISO9001 availabe, and according to IEC 521 international standard.
2. Low price and high reliability
105 C output capacitor
AC input power suitable for the world
Hight efficiency and low operation temperature
Soft-start current can reduce the AC input impact effecticly
With Short-circuit and owwerload protection
Compact size, light weight
100% full-load burning test
Installed with EMI filter, minimum wave
Low price and high reliability105 output capacitorAC input power suitable for the worldHight efficiency and low operation temperatureSoft-start current can reduce the AC input impact effecticlyWith Short-circuit and owwerload protectionCompact size, light weight100% full-load burning testInstalled with EMI filter, minimum wave.
| Model /Specification | S-25-5 | S-25-12 | S-25-15 | S-25-24 |
| DC output voltage | 5V | 7.5V | 12V | 24V |
| Output voltage error (Note2) | ± 2% | ± 1% | ± 1% | ± 1% |
| Rated output current | 5A | 18A | 12A | 6A |
| Output current rage | 0-5A | 0-2.1A | 0-1.7A | 0-1.1A |
| Wave and noise(Note3) | 50mVp-p | 100mVp-p | 100mVp-p | 100mVp-p |
| Inlet stability(Note4) | ± 0.5% | ± 0.5% | ± 0.3% | ± 0.2% |
| Load stability(Note5) | ± 1% | ± 0.5% | ± 0.3% | ± 0.2% |
| DC output power | 25W | 25.2W | 25.5W | 26.4W |
| Efficiency | 72%/115VAC | 76%/115VAC | 77%/115VAC | 80%/115VAC |
| Adjustable range for DC voltage | +10, -5% | ± 10% | ± 10% | ± 10% |
| AC input voltage range | 85~264VAC/47~63VAC; 120~370VDC |
| Input current | 0.6A/115V 0.35A/230V |
| AC impulse current | Cold-start current 15A/115V 30A/230V |
| Leakage current | < 0.75mA/240VAC |
| Overload protection | 105%~150% Type: PULSING HICCUP SHUTDOWN; Reset; auto recovery |
| Over-voltage protection | 115%~135% |
| High-temperature protection | ^ ^ |
| Temperature coefficient | ± 0.03% degrees Celsius (0~50 degrees Celsius) |
| Setup rise hold up time | 800ms, 50ms, 20ms/115VAC 300ms, 50ms, 80ms/230VAC |
| Vibration | 10~500Hz, 2G 10min. /1cycle, Period for 60min, Each axes |
| Withstand voltage | Input and output interval: 3KVAC, Input and enclosure: 1.5KVAC, Output and enclosure: 0.5KVAC |
| Isolation resistance | Input and output interval, Input and enclosure, Output and enclosure: 0500VAC/100M Ohms |
| Working temperature and humidity | -10 degrees Celsius~+60 degrees Celsius, 20%~90%RH |
| Store temperature and humidity | -20 degrees Celsius~+85 degrees Celsius, 10%~95RH |
| Overall dimension | 99*97*35mm |
| Weight | 0.37Kgs |
| Safety standards | Meet UL1012, TUV EN60950 |
| EMC standards | Meet IEC801-2, 3, 4, IEC555-2 |
Note: 1. The testing condition for the parameter above is: 230VAC input, rated load, 25 degrees Celsius 70%Rh, Humidity
2. Error, include the setting error, line stability and load stability. (Note: 5)
3. Wave test: adopting" A12" double wire for 20MHz, and 0.1uF& uF capacitor short-circuit for interrupting
4. Inlet voltage stability test: when is over load, the lowest voltage of inlet is representative to the highest voltage.
5. Load stability test: The load is from 0% to 100%, others 60%.
6. C2, 3, 11must be knocked down. |
