160kw 10000rpm Permanent Magnet Sychronous Motor

Name: 160kw 10000rpm Permanent Magnet Sychronous Motor
Brand: all-electronics-online.com
SKU: 712890445
Availability: InStock
Rating: 4.8 (142 reviews)

Price:	US $ 500-50000/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	XD-PMG
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Voltage:	Customize
Protect:	IP54
Bearing:	SKF
Warranty:	2years
Material:	NdFeB
Application:	Industrial
Operating Speed:	Low Speed
Operation Mode:	Generator
Ventilation:	Protection Type

Product Description

The motor speed, voltage, power can be customized according to the requirements, but its better to be no more than 15, 000 speed. The highest speed we can do is 24000rpm, The motor can be made as wind cooling or water cooling, AC or DC. The front cover of the motor could have flange front edge, the size and the output shaft can also be customized.

power	voltage	speed	Rated torque	Peak torque	Peak power	current	Current peak	Efficiency	weight	Chassis size
160kw	380V	10000	150Nm	260Nm	230KW	254A	450A	95.9%	170kg	Y180-240
315 kw	380V	18000	167Nm	240Nm	450KW	506A	720A	95.9%	180kg	Y180-260

Xinda Green Energy Co., Limited established in 2008, and have over 10years experience in new energy market, our company located in Nanjing China, we specialized in handling the business of green energy as below

1) Horizontal wind turbine generator from 300W to 200kw, vertical wind turbine from 300W-20kw, both on grid and off grid and also wind solar hybrid system. Both with CE certificate.

2) various kind of permanent magnet generator(0.05-3000kw), speed from 20rpm-20000rpm, which is widely used for wind turbine, hydro turbine, tidal turbine, ocean turbine, free energy and so on, high speed motor from 6000rpm to 15000rpm we can custom generator according customer request about speed, voltage, frequency, shaft size, cooling method and so on

3)both vertical and horizontal, small hydro turbine system(low head and higher head), such as franics turbine, kaplan turbine, tubular turbine and so on, all hydro turbine system design according water head and flow, power from 300W to 10MW.

We have over 10years in the market, know well about new energy market and products. Low speed generator, small hydro turbine are popular used in Europe, America, South Africa and so on area

Our partner manufacturers are committed to continuously improving our operations and meeting the needs of our customers through innovation and new product development. We work closely with them to optimize the performance and cost-effectiveness of their processes.

Any question, welcome to contact us. We will answer your questions at any time!
