18 Layer PCB Chip on Board RO4350b 10 Mil (0.254mm)
| Price: |
US $ 1.1/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-596-V5.96 |
| Board Thickness: |
1.0mm |
| Tg Value Of Board Material: |
60ºC |
| Inner Iayer Cu Thicknes: |
35 µm |
| Surface Cu Thickness: |
35 µm |
| Coverlay Colour: |
Yellow Coverlay / Green Solder Mask |
| Color Of Silkscreen: |
White |
| Peeling Test Of Coverlay: |
No Peelable |
| Surface Finish: |
Immersion Gold |
| RoHS Required: |
Yes |
| Function: |
100% Pass Electrical Test |
| Structure: |
Double-Sided FPC |
| Material: |
Polyimide |
| Combination Mode: |
Adhesive Flexible Plate |
| Conductive Adhesive: |
Conductive Silver Paste |
| Application: |
Application of Antenna |
| Insulation Materials: |
Polyimide |
| Brand: |
Bicheng |
Product Description
Company ProfileBicheng Enterprise Limited offers single sided / double sided and multilayer circuit boards.
We have been serving PCB electronics industry in Shenzhen, China since 2003.
Our advantages
* Your satisfied source to buy printed circuit boards (PCBs)
* All PCBs are 100% tested (flying probe or fixture test)
* Free panelizing
* Special price for partners
* On time delivery
* No minimum order quantity
* Worldwide shipping, door to door service
Our products
* PCB Prototypes and PCB Production
* Rigid PCB Fabrication
* Flexible PCB (FPC)
* PCB up to 32 layers
* RoHS complaint, Lead free PCBs
* Material: FR-4, High Tg (Tg170, Tg180), RO4350B, RO4003C, Polyimide
* Controlled Impedance
* Surface finish: HASL, HASL lead free, Immersion tin, Immersion silver, Immersion gold, gold
finger
* Blind vias
* 3 days to 4 weeks lead time
Printed Circuit Board
High Frequency PCB
Aluminum PCB
Flexible PCB
Bare board test (BBT)Multiple quality assuring procedures are performed before shipment. It includes:
Visual inspection
Flying probe
Impedance control
Solderability detection
AOI (automated optical inspection)
High voltage test
Micro section
Thermal stress test
Reliability test
Insulation resistance test
Ionic contamination test
Bicheng Flexible Printed Circuit Capability| No. | Specifications | Capabilities |
| 1 | Board Type | Single layer, Doulbe layer,
Multilayer, Rigid-Flex |
| 2 | Base Material | PI, PET |
| 3 | Copper Weight | 0.5oz, 1oz, 2oz |
| 4 | LED Maximum Size | 250 x 5000mm |
| 5 | General Maximum Size | 250 x 2000mm |
| 6 | Board Thickness | 0.03mm-3.0mm |
| 7 | Thickness Tolerance | ±0.03mm |
| 8 | Mininum Drill Hole | 0.05mm |
| 9 | Maximum Drill Hole | 6.5mm |
| 10 | Tolerance of Drill Hole | ±0.025mm |
| 11 | Thickness of Hole Wall | >= 8 um |
| 12 | Minimum Track/Gap of
Single Layer Board | 0.025/0.03mm |
| 13 | Minimum Track/Gap of Double
Layer and Multilayer Board | 0.03/0.040mm |
| 14 | Etching Tolerance | ±0.02mm |
| 15 | Minimum Width of Silk Legend | >= 0.125mm |
| 16 | Minimum Heigh of Silk Legend | >=0.75mm |
| 17 | Distance from Legend to Pad | >=0.15mm |
| 18 | Distance from Opening Solder
Mask of Drill Coverlay to Track | >=0.03mm |
| 19 | Distance from Opening Solder
Mask of Punching Coverlay to Track | >=0.03mm |
| 20 | Thickness of Immersion Nickel | 100-300u" |
| 21 | Thickness of Immersion Gold | 1-3u" |
| 22 | Thicnkess of Immersion Tin | 150-400u" |
| 23 | Minimum Electrical Testing Pad | 0.2mm |
| 24 | Minimum Tolerance of Outline
(Normal Steel Mould Punch) | ±0.1mm |
| 25 | Minimum Tolerance of Outline
(Precision Steel Mould Punch) | ±0.05mm |
| 26 | Mininum Radius of
Bevel Angle (Outline) | 0.2mm |
| 27 | Stiffner Material | PI, FR-4, 3M Adhesive, PET, Steel Sheet |
| 28 | RoHs | Yes |
| 29 | Solder Mask Colour | Yellow, White, Black, Green |
